Thanks! If you want the Puddle Lamp, that model is and has been sold out for about a month now. They have a power Folding model that is still in stock. With the 1A mirrors, their mirror connector doesn’t come PnP out of the box. There are 2 wires that don’t land into the connector. So we have to think about provisioning that. As for harnesses, I have 1-2 sets left. If you purchase a Set today, I can guarantee shipment out tomorrow. If power Fold is not critical, you can get part # https://www.am-autoparts.com/products/side-view-mirrors/AM-2481561241.html It’s $295 for this set and I won’t need them in my possession. You’ll just need a set of my PnP Harnesses. Let me know. Thanks, Phil Sent from my iPhone using Tapatalk
Basically - your HMI only has (2) USB outputs. It can only feed (2) Hubs. In your case, and in the case of us 2016+ owners that wants to do this... we have 3 hubs. - Glove Box (1 USB) - Front Console (2 USB) - Inside Compartment (2 USB) In order to get all 3 locations live, 1 cable will go from the HMI to the Glove. This is the existing Green to USB cable (already present) This leaves you with the Black USB port on the HMI. From here, you have to go the front console USB (Using a Black to Grey usb Cable). Then, the other port of this hub feeds the inside Compartment hub PM and can send pics of how this is done. Sent from my iPhone using Tapatalk
Yep. If you take the front Dual USB out and look at the back side, you should see (2) USB Ports and a 6-pin. One of the USB ports is an input (comes from the Black Port of the HMI - is Grey coming in). Should be a black to Grey USB Cable. THEN, the other port is an output. This needs a Black to Grey USB Cable to feed the inside compartment USB Hub. IF you are using the brown USB Cable that comes with the console, then you need to figure which color combination you need. The key is coming FROM the HMI to the front USB port first. Then feed off of that one to the inside compartment. So essentially, you need (2) Black to Grey USB Cables.
Yep. The 2nd Cig lighter up front is on a separate circuit, but can be easily tapped by the one next to it. For the USB ports... do you have one in the glove box? Is it working? The HMI only has (2) USB outputs that you can use. So we have to be “creative” with how to wire it up. IF the front USB is a dual, you have a 16/17 model hub. It has an Input and an output, and you can daisy chain from it. IF you have a triple USB up front, this is the 14/15 version and only has (1). Input in the back. Sent from my iPhone using Tapatalk
For the outlet plug... yes. I don’t know what the requirements are for adding that. I know the inverter is behind the radio. The USB Ports and 12V Cig lighter Plugs should be easy. Sent from my iPhone using Tapatalk
My harness will not have provisions for this. This connection is dependent on the DC to AC Adapter behind the radio.
The two orange plugs is for the 110V Outlet. Do you not have that now under the radio?
pgamboa replied to NIXONRIDE's topic in 2014 / 2015 / 2016 / 2017 / 2018 Silverado & Sierra Accessories & ModificationsMy understanding is that as long as it from the same year... but I advise to cross check with WAMS before you buy. Sent from my iPhone using Tapatalk
***UPDATE*** - Just exhausted a 1,000 count bag of zip ties! Each harness takes 2 zip ties, so if you do the math, I’ve built/Shipped 500 Harnesses! Thank you for the support! Also - I am SOLD OUT! I may have 1-2 harness sets left and unsure of when more are coming. Please check with me on lead times before ordering. Thanks! Sent from my iPhone using Tapatalk
In order for the USB hub to work, it needs the 6 pin and the USB. The HMI has two usable USB ports. Green and black. If you have the (2) Port USB up front, there should be (2) USB ports in the back. The left side port accepts a grey USB. The right side is an output an accepts a black USB cable. If yo want to keep the glove box USB (Green - Female USB Receptacle), then you’ll need. Black -> Grey (from HMI to front USB) Grey -> Brown (to feed the brown female jack in the front). Or Black to Grey (if you completely removed the full console harness). Hope this makes sense. Sent from my iPhone using Tapatalk
Wireless Charging only needs power and ground to work. Can be tapped by existing power and ground Sent from my iPhone using Tapatalk
Umm...no http://www.gm-trucks.com/forums/topic/196138-2016-silverado-lt-fold-your-dl3-mirrors-with-your-fob-like-an-ltz/ Sent from my iPhone using Tapatalk
PM me. I offer this as a solution as well Sent from my iPhone using Tapatalk
pgamboa replied to block8head's topic in 2014 / 2015 / 2016 / 2017 / 2018 Silverado & Sierra Accessories & ModificationsWhen I sent my cluster off to get programmed, I also inquired about the possibility of adding Front Park Assist. When I did the bumper swap, I found a black bumper that had the sensor holes. I added the sensors and the wait began. Well, here it is...If you can get passed the temporary wiring... Front Park Assist Retrofit. Now I get to spend more time getting wiring in place and done right. Thanks to @ Justin101714 [email protected] for their help on this! Sent from my iPhone using Tapatalk
pgamboa replied to block8head's topic in 2014 / 2015 / 2016 / 2017 / 2018 Silverado & Sierra Accessories & ModificationsSwap literally took maybe 10 minutes. Longer to record than it was to do the swap. Lol Sent from my iPhone using Tapatalk
