Bowtie Removal Question


  • Please log in to reply
15 replies to this topic

#1 11 CC Silverado

11 CC Silverado

    Enthusiast

  • Member
  • 317 posts
  • Location:League City, Tx
  • Gender:Male

Posted 04 October 2009 - 09:06 AM

I've searched for 2 days now and can't find the answer I need.

I just bought an 08 Tahoe LTZ from a friend and am trying to find out if the bowtie on the rear lift gate is bolted down or stuck on with tape? Looking at it, it looks like it's just double-sided tape.

Also, what's the best way to remove the bowtie on the grill? I'm thinking about replacing it with this one. http://cgi.ebay.com/...P...RK:MEWAX:IT

Thanks in advance.
Posted Image
11 Silverado 2500HD | 6.0 | 3.73 | Sheer Silver Metallic | Color Matched Bowties | Weathertech Floorliners | Rear Wheel House Liners (22738993)

13 Explorer Limited | Kodiac Brown Metallic

11 Forest River Flagstaff 831FLSS

#2 andymiller

andymiller

    Enthusiast

  • Member
  • 183 posts
  • Location:Northeast NC
  • Gender:Male

Posted 04 October 2009 - 11:15 AM

The one on the trucks are taped. I just kept soaking the sides with gu-gone till it was ready to pull off. Some use 100lb fishing line and go in behind it
2004 GMC Sierra 4x4-
285/70/17 Falken Rocky Mountain ATS/ Falken ORC 909 wheels
2" TBar Crank w/ 3.5" block in rear to keep the rake.
Diablo Pretador programmer. Single Magnaflow Muffler. Line-X, Tonneau Pro Cover.

#3 markintexas

markintexas

    Enthusiast

  • Member
  • 16 posts
  • Location:Texas
  • Gender:Male

Posted 04 October 2009 - 11:59 AM

The one on the trucks are taped. I just kept soaking the sides with gu-gone till it was ready to pull off. Some use 100lb fishing line and go in behind it


Did you get any scratching or paint damage when using the fishing line?

Thanks,

Mark
Posted Image
2007 White GMC Sierra Texas Edition 5.3L
1997 Hunter Green Chevrolet S10 Vortec V6 4.3L
1997 Fire Red Pontiac Formula 1 Firebird 350


#4 jeffbco

jeffbco

    Enthusiast

  • Member
  • 118 posts

Posted 04 October 2009 - 05:19 PM

I've searched for 2 days now and can't find the answer I need.

I just bought an 08 Tahoe LTZ from a friend and am trying to find out if the bowtie on the rear lift gate is bolted down or stuck on with tape? Looking at it, it looks like it's just double-sided tape.

Also, what's the best way to remove the bowtie on the grill? I'm thinking about replacing it with this one. http://cgi.ebay.com/...P...RK:MEWAX:IT

Thanks in advance.


I'm curious too - I have an 09 Suburban. On my 08 Avalanche, the bow tie was stuck on with tape but there were also 2 or 3 (can't remember) centering pins on the back of the bow tie that fit into holes in the tailgate. On an 08 2500HD, it was just tape, pins. Dental floss or fishing line with heat from a hair dryer makes removal easy. Then Goo Gone or other solvent followed by some polish - no scratches or outlines.

Edited by jeffbco, 04 October 2009 - 05:21 PM.


#5 BigBlueSilvy

BigBlueSilvy

    Senior Enthusiast

  • Member
  • 1,041 posts
  • Location:US
  • Gender:Male

Posted 04 October 2009 - 05:55 PM

i dont know about the new ones, but changing my grille emblem i had to take the fan shroud off and then it was just to screws holding the bow tie into the grille.
2005 Chevy Silverado Z-71
2009 Arctic Cat Mud Pro 700

#6 dlewis1111

dlewis1111

    Senior Enthusiast

  • Member
  • 1,091 posts
  • Name:David
  • Location:Phenix City, AL
  • Gender:Male
  • Drives:2008 Silvefrado

Posted 04 October 2009 - 06:40 PM

The one on the trucks are taped. I just kept soaking the sides with gu-gone till it was ready to pull off. Some use 100lb fishing line and go in behind it


Heat gun and dental floss.....followed by goo gone to clean up then a clay bar and finally was

Posted Image


#7 downsized

downsized

    Enthusiast

  • Member
  • 472 posts
  • Location:Slocala, Florida

Posted 05 October 2009 - 12:09 PM

IF the Tahoes grille-tie is like the Silvy, the backside looks like this. There are a couple of wedge shaped tangs on the "soccer goal" that lock it to the grille. You can disengage them with a tiny screwdriver from the backside and it will pop off, again IF it's the same as the trucks. I had to remove the facia between the radiator and grill to gain access and field of view too, but it's just held on with pop-fasteners or whatever they're called.
Posted Image

Edited by downsized, 05 October 2009 - 12:12 PM.


Posted Image
5.3l 4l60 BB tuned, Magnaflowed, Belltech'd 2", Line-X'd gray, GM ovals and caps, Amp step'd, DIC'd, and clean (usually)

#8 Johnson8537

Johnson8537

    Enthusiast

  • Member
  • 183 posts
  • Location:Oregon
  • Gender:Male

Posted 05 October 2009 - 12:12 PM

IF the Tahoes tie is like the Silvy, the backside looks like this. There are a couple of wedge shaped tangs on the "soccer goal" that lock it to the grille. You can disengage them with a tiny screwdriver from the backside and it will pop off, again IF it's the same as the trucks.
Posted Image



I have mine removed one the rear!! I can post pics if you need them!! Just a little heat and fishing Line (and Goof OFF) Easy 10-20 Min deal.
2007 Tahoe LTZ 4x4 - NAV- Back up cam- Dual DVDs in headrests, 22" Wheels, Eibach lowing 2" springs, tinted windows, billet grill. Subs, Alpine Amp, Bose factory speakers. Plus all the LTZ has to offer!

SOLD:
2007 Silverado Crew Cab 4x4 Lt2-FabTech 6" Lift with 20" XD wheels on 35" Toyos, Black Nerf Bars
Billet Grill, Tinted Windows, Line XBed Liner, Hypertech programer, ACCESS Tonneau cover.
WET OKOLE Seat covers front and back, Pioneer Head unit with Ipod hook up and handsfree Bluetooth.
My Garage

#9 502chevy

502chevy

    Enthusiast

  • Member
  • 112 posts
  • Location:Louisville, KY
  • Gender:Male

Posted 05 October 2009 - 01:01 PM

so on the tailgate there isn't any centering pins?

#10 Blackout07

Blackout07

    Sometimes there's justice. Sometimes there's just us.

  • Member
  • 4,112 posts
  • Name:Matt
  • Location:Texas
  • Gender:Male
  • Drives:07 Silverado 4x4

Posted 05 October 2009 - 02:34 PM

so on the tailgate there isn't any centering pins?



Yes there are. You can remove it but you will need to replace the piece that it mounts to with one from a Yukon, as they dont have emblems. And the front one isn't like the Silverados. It has two center pens and a small amount of double sided tape.

4c2aa7d2-4666-4a5a-a00f-0b17d4c5fb7b_zps


#11 Westandover

Westandover

    Enthusiast

  • Member
  • 7 posts
  • Location:Minnesota

Posted 05 October 2009 - 10:09 PM

I did some research on the same topic for an 2009 Suburban LTZ. Like your Tahoe, the tail gate emblem DOES HAVE HOLES that would to be filled or covered with another piece of some sort. The pickups/trucks are much easier and do not have holes.

I got a combo emblem kit off ebay and the back piece just wouldn't tape on as close to the body to look like a good OEM emblem.

On the front, however, that was a different story. Reaching in into the grill area, I was able to remove the emblem without removing any additional items other than simply lifting the hood. The emblem was held in place with a weird looking nut, but nonetheless was truly a nut. The nut twists onto a plastic bolt and with some unscrewing, the emblem eventually came off and enabled me to put on a new black emblem in its place. The new emblem is a powder-coated black, so should endure the front elements hitting it everyday.

Hope this helps. In summary on a new body Tahoe/Suburban, take care on the rear emblem, but have fun with the front.

#12 11 CC Silverado

11 CC Silverado

    Enthusiast

  • Member
  • 317 posts
  • Location:League City, Tx
  • Gender:Male

Posted 06 October 2009 - 07:26 AM

I did some research on the same topic for an 2009 Suburban LTZ. Like your Tahoe, the tail gate emblem DOES HAVE HOLES that would to be filled or covered with another piece of some sort. The pickups/trucks are much easier and do not have holes.

I got a combo emblem kit off ebay and the back piece just wouldn't tape on as close to the body to look like a good OEM emblem.

On the front, however, that was a different story. Reaching in into the grill area, I was able to remove the emblem without removing any additional items other than simply lifting the hood. The emblem was held in place with a weird looking nut, but nonetheless was truly a nut. The nut twists onto a plastic bolt and with some unscrewing, the emblem eventually came off and enabled me to put on a new black emblem in its place. The new emblem is a powder-coated black, so should endure the front elements hitting it everyday.

Hope this helps. In summary on a new body Tahoe/Suburban, take care on the rear emblem, but have fun with the front.



Thanks, that's what I needed to know. Guess I'll just look into color matching the emblems.
Posted Image
11 Silverado 2500HD | 6.0 | 3.73 | Sheer Silver Metallic | Color Matched Bowties | Weathertech Floorliners | Rear Wheel House Liners (22738993)

13 Explorer Limited | Kodiac Brown Metallic

11 Forest River Flagstaff 831FLSS

#13 ccbebow

ccbebow

    Enthusiast

  • Member
  • 11 posts
  • Location:Louisiana
  • Gender:Male

Posted 10 October 2009 - 08:39 PM

gasoline works great with the removel of emblems. Just spray gasoline around the emblems and then use any fishing line u want to then get behind the emblem and pull it behind and it falls right off. There will be some of the 3M double sided foam tape left but just use gas and a microfiber towel to remove the tape and glue.

#14 daddy

daddy

    "It's the one that says Bald Motherf*cker."

  • Member
  • 14,970 posts
  • Location:Indiana
  • Gender:Male

Posted 10 October 2009 - 09:20 PM

I did some research on the same topic for an 2009 Suburban LTZ. Like your Tahoe, the tail gate emblem DOES HAVE HOLES that would to be filled or covered with another piece of some sort. The pickups/trucks are much easier and do not have holes.

I got a combo emblem kit off ebay and the back piece just wouldn't tape on as close to the body to look like a good OEM emblem.

On the front, however, that was a different story. Reaching in into the grill area, I was able to remove the emblem without removing any additional items other than simply lifting the hood. The emblem was held in place with a weird looking nut, but nonetheless was truly a nut. The nut twists onto a plastic bolt and with some unscrewing, the emblem eventually came off and enabled me to put on a new black emblem in its place. The new emblem is a powder-coated black, so should endure the front elements hitting it everyday.

Hope this helps. In summary on a new body Tahoe/Suburban, take care on the rear emblem, but have fun with the front.



Thanks, that's what I needed to know. Guess I'll just look into color matching the emblems.


There is a another option.

You can order the rear hatch handle cover (the thing the rear bow tie is attached to) from the Yukon and have it painted to match and use that in place of the Tahoe version.

Check out this thread, this should show you exactly what's up! I'd suggest going with the Yukon part for the cleaner look! :lol:

http://www.gm-trucks...showtopic=82226

Hope that helps.

Edited by daddy, 10 October 2009 - 09:20 PM.

Posted Image


#15 11 CC Silverado

11 CC Silverado

    Enthusiast

  • Member
  • 317 posts
  • Location:League City, Tx
  • Gender:Male

Posted 11 October 2009 - 07:39 AM

I did some research on the same topic for an 2009 Suburban LTZ. Like your Tahoe, the tail gate emblem DOES HAVE HOLES that would to be filled or covered with another piece of some sort. The pickups/trucks are much easier and do not have holes.

I got a combo emblem kit off ebay and the back piece just wouldn't tape on as close to the body to look like a good OEM emblem.

On the front, however, that was a different story. Reaching in into the grill area, I was able to remove the emblem without removing any additional items other than simply lifting the hood. The emblem was held in place with a weird looking nut, but nonetheless was truly a nut. The nut twists onto a plastic bolt and with some unscrewing, the emblem eventually came off and enabled me to put on a new black emblem in its place. The new emblem is a powder-coated black, so should endure the front elements hitting it everyday.

Hope this helps. In summary on a new body Tahoe/Suburban, take care on the rear emblem, but have fun with the front.



Thanks, that's what I needed to know. Guess I'll just look into color matching the emblems.


There is a another option.

You can order the rear hatch handle cover (the thing the rear bow tie is attached to) from the Yukon and have it painted to match and use that in place of the Tahoe version.

Check out this thread, this should show you exactly what's up! I'd suggest going with the Yukon part for the cleaner look! :lol:

http://www.gm-trucks...showtopic=82226

Hope that helps.



Thanks for the link. I'll be calling the dealer tomorrow for a price on the cover. The part # in the link turned up nothing at gmpartsdirect.
Posted Image
11 Silverado 2500HD | 6.0 | 3.73 | Sheer Silver Metallic | Color Matched Bowties | Weathertech Floorliners | Rear Wheel House Liners (22738993)

13 Explorer Limited | Kodiac Brown Metallic

11 Forest River Flagstaff 831FLSS
