Tpms Reset


  • Please log in to reply
19 replies to this topic

#1 Chevy all the way

Chevy all the way

    Enthusiast

  • Member
  • 38 posts
  • Location:Omaha, NE

Posted 22 March 2010 - 07:10 PM

Does anyone know how to reset TPMS after you rotate your tires. My gauges are reading backwards now for front and rear.
Posted Image


  • 2009 Chevy Silverado LTZ CC 1500 4x4
  • 6in BDS suspension lift, 35" Toyo M/T, 20" Moto Metal 951
  • Flowmaster 50 Series/Truxedo low profile Tunneau cover
  • Raptor Magnum Series 5" Oval nerf bars/ LinexSpray-In Bed Liner
  • Predator Diablo tune

#2 kdixer

kdixer

    Enthusiast

  • Member
  • 696 posts
  • Location:WV
  • Gender:Male

Posted 22 March 2010 - 07:21 PM

I keep my owners manual in the glove box just for instances just like this. :)

If you have keyless entry then hold lock and unlock on the remote at the same time for like 5 seconds or until the horn beeps. Then starting at drivers front let air out until you hear the horn beep then go to the passenger front and release air until the horn beeps, then the passenger rear, then the drivers rear.
The intention of my posts are simply an expression of my personal opinion. If they offend you, let me go ahead and appologize now. If that is not good enough, why do you care what i think? You probably don't even know me anyway.

#3 mato

mato

    Enthusiast

  • Member
  • 384 posts
  • Location:Cleveland, OH
  • Gender:Male

Posted 22 March 2010 - 07:37 PM

Each TPMS sensor has a unique identification code.

Any time you rotate your vehicle's tires or replace one

or more of the TPMS sensors, the identification codes

will need to be matched to the new tire/wheel position.

The sensors are matched to the tire/wheel positions in

the following order: driver side front tire, passenger side

front tire, passenger side rear tire, and driver side rear

tire using a TPMS diagnostic tool. See your dealer for

service.

The TPMS sensors can also be matched to each tire/

wheel position by increasing or decreasing the tire's air

pressure. If increasing the tire's air pressure, do not

exceed the maximum inflation pressure indicated on the

tire's sidewall.

To decrease air-pressure out of a tire you can use the

pointed end of the valve cap, a pencil-style air pressure

gauge, or a key.

You have two minutes to match the first tire/wheel

position, and five minutes overall to match all four tire/

wheel positions. If it takes longer than two minutes, to

match the first tire and wheel, or more than five minutes

to match all four tire and wheel positions the matching

process stops and you need to start over.



The TPMS sensor matching process is outlined below:

1. Set the parking brake.

2. Turn the ignition switch to ON/RUN with the

engine off.

3. Press the Remote Keyless Entry (RKE)

transmitter's LOCK and UNLOCK buttons at the

same time for approximately five seconds. The

horn sounds twice to signal the receiver is in

relearn mode and TIRE LEARNING ACTIVE

message displays on the DIC screen.

If your vehicle does not have RKE, press the

Driver Information Center (DIC) vehicle information

button until the PRESS V TO RELEARN TIRE

POSITIONS message displays. The horn sounds

twice to signal the receiver is in relearn mode and

TIRE LEARNING ACTIVE message displays on

the DIC screen.

If your vehicle does not have RKE or DIC buttons,

press the trip odometer reset stem located on the

instrument panel cluster until the PRESS V TO

RELEARN TIRE POSITIONS message displays.

The horn sounds twice to signal the receiver is in

relearn mode and TIRE LEARNING ACTIVE

message displays on the DIC screen.

4. Start with the driver side front tire.

5. Remove the valve cap from the valve cap stem.

Activate the TPMS sensor by increasing or

decreasing the tire's air pressure for five seconds,

or until a horn chirp sounds. The horn chirp, which

may take up to 30 seconds to sound, confirms that

the sensor identification code has been matched to

this tire and wheel position.

6. Proceed to the passenger side front tire, and

repeat the procedure in Step 5.

7. Proceed to the passenger side rear tire, and repeat

the procedure in Step 5.

8. Proceed to the driver side rear tire, and repeat the

procedure in Step 5. The horn sounds two times to

indicate the sensor identification code has been

matched to the driver side rear tire, and that the

TPMS sensor matching process is no longer

active. The TIRE LEARNING ACTIVE message on

the DIC display screen goes off.

9. Turn the ignition switch to LOCK/OFF.

10. Set all four tires to the recommended air pressure

level as indicated on the Tire and Loading

Information label.

11. Put the valve caps back on the valve stems.






Edited by mato27, 22 March 2010 - 07:42 PM.

2008 Silverado Z71 4x4 Ext Cab 5.3L
Chrome Westin Platinum Side Steps l WeatherTech Floorliners l Husky GearBox Underseat Storage l WeatherTech Rain Guards l aFe Pro-Dry S Air Filter l GM Molded Splash Guards l WeatherTech Bug Deflector l DualLiner l G4 Elite Fold-A-Cover Tonneau l GMPP Sport Exhaust l LT2 Console l ReadyLift 1.5" Leveling Kit l BFG T/A KO 275/65/18 l Custom BlackBear Tune

#4 pjb0422

pjb0422

    Enthusiast

  • Member
  • 433 posts
  • Location:Eureka, MO
  • Gender:Male
  • Drives:2014 Silverado CC LTZ Z71

Posted 23 March 2010 - 06:27 AM

A total PITA!! :) GM should come up with a more user-friendly way of doing this. The trick is to let air out for the first 5 seconds and then wait 30 seconds for the horn to beep. It may take several attempts at getting all of your sensors reset.

Phil
Black Silverado Club

2014 Black Silverado CC LTZ 4x4 Cocoa/Dune interior.  Weathertech floor liners, Line-X liner, Fold-a-Cover tonneau


#5 spurshot

spurshot

    Senior Enthusiast

  • Member
  • 3,383 posts
  • Location:SoCalif
  • Gender:Male

Posted 23 March 2010 - 06:41 AM

A total PITA!! :) GM should come up with a more user-friendly way of doing this. The trick is to let air out for the first 5 seconds and then wait 30 seconds for the horn to beep. It may take several attempts at getting all of your sensors reset.


Yeah, like pushing a reset button on the dash to relearn all positions at once.




2014 Sierra SLT All Terrain 5.3 Crew 6 1/2 ft bed, 305/60-18 Cooper ST Maxx, 1 1/2" level, 5000k Morimoto HID, 4 Baja Designs SII LED lights, AMP Power Steps, Bushwacker flares, Foglights w/High Beams mod, Wilwood 14.25" 6 piston front brakes, Snugtop Hi-Liner Sport.

2008 Silverado 1500 VMax Crew 4x4 LTZ, NHT


#6 Matt_

Matt_

    Senior Enthusiast

  • Member
  • 5,108 posts
  • Location:central NJ

Posted 23 March 2010 - 07:35 AM

A total PITA!! :) GM should come up with a more user-friendly way of doing this. The trick is to let air out for the first 5 seconds and then wait 30 seconds for the horn to beep. It may take several attempts at getting all of your sensors reset.


Yeah, like pushing a reset button on the dash to relearn all positions at once.


it wouldnt be able to identify the sensor locations in that case. tpms systems that dont tell you the pressures at each tire have a single reset button.

honestly... its not that hard to do. ive reset mine numerous time for new tire/wheel combos and new rotations and ive never had it not work on the first try..... i really dont know how much easier they can make it......
When Hell Freezes Over, I'll Ski There Too!!
2007 Jeep Commander 5.7L Hemi: Pics Here
2008 GMC Sierra Denali AWD (SOLD):Pics Here
2005 1500 Crew Cab. 8" lift w/37s (SOLD): Pics Here

#7 brims

brims

    Senior Enthusiast

  • Member
  • 1,605 posts
  • Location:CA
  • Gender:Male

Posted 23 March 2010 - 11:21 AM

A total PITA!! :) GM should come up with a more user-friendly way of doing this. The trick is to let air out for the first 5 seconds and then wait 30 seconds for the horn to beep. It may take several attempts at getting all of your sensors reset.


Yeah, like pushing a reset button on the dash to relearn all positions at once.


it wouldnt be able to identify the sensor locations in that case. tpms systems that dont tell you the pressures at each tire have a single reset button.

honestly... its not that hard to do. ive reset mine numerous time for new tire/wheel combos and new rotations and ive never had it not work on the first try..... i really dont know how much easier they can make it......


I have never been able to get the air pressure method to work.

My mom's Jeep doesn't need to be relearned, there are receivers at each wheel well that pick up the individual sensors. A lot better system than the stupid thing we have.
Posted Image
2008 Chevrolet Silverado 1500 Extended Cab Standard Box, 2LT, 4x2, 5.3L FlexFuel, 3.73 G80, Graystone Metallic, General Grabber HTS 245/70R17
Mods: Line-X over the rail, WeatherGuard Crossbox, Optima Red Top, MagHytec Differential Cover, Rough Country 2" leveling kit, Corvette Servo, AEM Brute Force Intake, Black Bear tune, Hayden 679 aux trans cooler, Hawk pads, Bilstein shocks, Dual Aeroforce Interceptors, Extang Snapless Full Tilt Tool Box Tonneau
Future mods: 2 low/6 high
Possible mods: rear sway bar, blacked out front and rear bumpers

#8 Diesail

Diesail

    Enthusiast

  • Member
  • 496 posts

Posted 23 March 2010 - 12:43 PM

I think it works great. I do the key fob thing and make a quick lap around DEFLATING each tire until I get the beep. Now that it has learned I make one more lap and adjust them to there correct PSI. Couldn't be easier IMO.

#9 Wires

Wires

    Enthusiast

  • Member
  • 699 posts

Posted 23 March 2010 - 03:14 PM

Ok, that's interesting info.

I didn't even realize that you had to do that......

I guess I need to make a journey to the garage and get-r-done....

#10 zaemo

zaemo

    Enthusiast

  • Member
  • 10 posts
  • Location:Atlanta, GA

Posted 28 March 2010 - 09:33 AM

I tried several times to get my '07 to relearn tire position. Took it to the dealer in in about less than a minute, the service rep had grabbed a hand held computer unit, pressed the Relearn Tire Position button, walked around and pointed the unit at the valve stems until the horn honked, and done. No charge. Don't know why I couldn't do it myself. Maybe I needed to try a few more times?

Z

#11 LAGA

LAGA

    Enthusiast

  • Member
  • 266 posts
  • Location:Alsip Il
  • Gender:Male

Posted 28 March 2010 - 09:54 AM

I have tried many times to get mine to work. Never happened
07 Silverado ECSB NBS VMAX 2WD LT2, Outlaw CAI, Black Leer Hard Tonneau Cover, Westin Platinum Series Black Step Tubes, Huskey molded mud flaps, Escort radar detector, Blackbear Performance tune, Vette Servo, 4.10 Gears, Lead Foot

Posted Image



Four legs good, two legs better

#12 Diesail

Diesail

    Enthusiast

  • Member
  • 496 posts

Posted 28 March 2010 - 10:28 AM

I have tried many times to get mine to work. Never happened



Just rotated my tires yesterday, here are the steps I took

1) Got in the truck and set the parking brake.
2) Turned the key on, yes on and not running. Repeat, not the accessory position.
3) Pushed and held the lock and unlock buttons on the FOB until the horn beeped twice.
4) Stepped out and went to the driver's side front and using the end of a tire gauge deflated the front tire until the horn beeped.
5) Moved to passenger side front and repeated, then passenger rear and finally driver's rear. After the last tire it beeps twice.
6) Went back around and deflated or inflated accordingly.

One observation I did make, I have a 2500HD and tires are 80 rear and 60 front. The tires with 80 PSI deflated much faster and it took just a few seconds get a beep. The tires at 60 took MUCH longer to get the beep, so at the lower pressure of a 1500 I would think it would take even longer. Also you have a 2 minute limit per tire so that is why I think it much easier to deflate then to inflate as you can move around the truck faster.

Edited by Diesail, 28 March 2010 - 10:29 AM.


#13 CalixEros

CalixEros

    Enthusiast

  • Member
  • 143 posts

Posted 28 March 2010 - 10:38 AM

If you're having trouble getting it to work try running a large magnet across the sensor as you're letting air out. I do this on the Vette and don't even need to let any air out but I do on the truck. I have a friend's truck where I can just use the magnet, so I'm guessing there are differences in the TPMS that's making it easier for some than others... I got a big magnet from Harbor Freight for ~$5 that works great. An old speaker magnet would work well too.

#14 DoMDrty

DoMDrty

    Enthusiast

  • Member
  • 246 posts
  • Location:GA
  • Gender:Male

Posted 28 March 2010 - 01:42 PM

Reset my sensors yesterday because of the new wheels, and got it on the second try.
Posted Image

#15 cgalford

cgalford

    Enthusiast

  • Member
  • 142 posts
  • Location:Hermosa Beach, CA

Posted 28 March 2010 - 03:40 PM

I could never get mine to work and after A LOT of searching I found a service bulletin for certain types of valve stem type (rubber I think it was) letting air out causes a harmonic vibration so the sensor thinks it rolling instead of sending position information and that the programming tool was the only was to get them to register.
2008 Hummer H2 6.2/6Spd Black/Black
2009 Yamaha R1 CVMA Racing License #297
