Leak In The Transfer Case


  • Please log in to reply
13 replies to this topic

#1 eagles1

eagles1

    Enthusiast

  • Newbie
  • 4 posts

Posted 30 May 2010 - 09:06 PM

I have q 2002 Escalade 4wd . It has about 120,000 Miles on it .On a recent vacation trip the rear window was covered in oil and a call to the local mechanic told me the transfer case seal was bad . He put a Napa seal on it . It wasnt far down the road I realized it was NOT fixed at all . When I got home I went to another mechanic and told him what I just had done . He said , the transfer case seal was probably not put on right, loose bolts or crooked . he laso did not like Napa seals He put a Timken seal on it . When he was doing it he said their was a small brass bushing under their that had just a "little" wear on on it and it should not be enough to cause any problems . Well somthing is wrong !!!! The truck still leaks exaclty the same . So, what should I try next , what could it be most likely and how expensive is it since I have little $ at the moment ? Thanks a lot for any suggestions .

#2 jro909

jro909

    Your Own Personal Jesus

  • Member
  • 4,079 posts
  • Location:Wisconsin
  • Gender:Male
  • Drives:04 1500 Silverado

Posted 30 May 2010 - 10:12 PM

uh rear window as in far back rear window? because that would be wild if the transfer case threw oil up there...btw bump
RCLB 5.3, 3.42 gears, Z85/82 Bilstein Hds, General AT2 Grabbers

Man fears what he does not understand- Anton LaVey

Old People Drive Slow To Make The Most Of The Time They Have Left

Member of the Red Truck Club


Proud Vortec Owner

#3 thearborbarber

thearborbarber

    Enthusiast

  • Member
  • 481 posts
  • Location:SoDak
  • Gender:Male

Posted 30 May 2010 - 10:20 PM

Try these posts;

http://www.gm-trucks...amp;hl=pump rub

http://www.gm-trucks...amp;hl=pump rub
2009 GMC Sierra 1500
1999 Chevy Camaro Z28 (Mr. Hyde)
2004 Honda Civic (Dr. Jeckel)

#4 hpracing10

hpracing10

    Enthusiast

  • Member
  • 111 posts

Posted 30 May 2010 - 10:23 PM

Not too sure what transfer case you have, but I have an 03 silverado pickup and my transfer case started to leak too. Apparently on a certain model transfer case, there is an oil pump up inside there and a small clip sometimes works its way loose and over time will wear an actual very small pinhole in the side of the case. It usually happens on the tailshaft of the transfer case, way up on the side almost to the top on the passenger side. The dealer wanted $900 to fix mine, said he would have to replace the whole back half of the case. I took it home, located the hole with a magnifying glass, cleaned it up REAL good and took clear RTV silicone and sealed it up. The dealer told me it would never work, its been 50,000 miles and I have yet to see it leak again. Hope that helps.

#5 eagles1

eagles1

    Enthusiast

  • Newbie
  • 4 posts

Posted 30 May 2010 - 11:08 PM

uh rear window as in far back rear window? because that would be wild if the transfer case threw oil up there...btw bump



Oh Yes all over it , at high way speed

#6 eagles1

eagles1

    Enthusiast

  • Newbie
  • 4 posts

Posted 30 May 2010 - 11:19 PM

Not too sure what transfer case you have, but I have an 03 silverado pickup and my transfer case started to leak too. Apparently on a certain model transfer case, there is an oil pump up inside there and a small clip sometimes works its way loose and over time will wear an actual very small pinhole in the side of the case. It usually happens on the tailshaft of the transfer case, way up on the side almost to the top on the passenger side. The dealer wanted $900 to fix mine, said he would have to replace the whole back half of the case. I took it home, located the hole with a magnifying glass, cleaned it up REAL good and took clear RTV silicone and sealed it up. The dealer told me it would never work, its been 50,000 miles and I have yet to see it leak again. Hope that helps.


Great m this is good to know . Now I have read if this is the case it does not drip on the ground , mine does. Did yours drip visably on the ground when the truck was parked ?

#7 hockeypro1411

hockeypro1411

    Senior Enthusiast

  • Member
  • 1,638 posts
  • Location:New Lenox, Illinois
  • Gender:Male

Posted 31 May 2010 - 12:19 AM

Not too sure what transfer case you have, but I have an 03 silverado pickup and my transfer case started to leak too. Apparently on a certain model transfer case, there is an oil pump up inside there and a small clip sometimes works its way loose and over time will wear an actual very small pinhole in the side of the case. It usually happens on the tailshaft of the transfer case, way up on the side almost to the top on the passenger side. The dealer wanted $900 to fix mine, said he would have to replace the whole back half of the case. I took it home, located the hole with a magnifying glass, cleaned it up REAL good and took clear RTV silicone and sealed it up. The dealer told me it would never work, its been 50,000 miles and I have yet to see it leak again. Hope that helps.


Great m this is good to know . Now I have read if this is the case it does not drip on the ground , mine does. Did yours drip visably on the ground when the truck was parked ?


The case usually won't drip noticeably. The leak is very small and is usually detected when they notice fluid all over the case, or when the case completely fails due to a lack of fluid. There's no way the pump rub hole would spray fluid. Let alone spray it enough to get it on a window. The pump rub hole is TINY.

Posted Image



#8 eagles1

eagles1

    Enthusiast

  • Newbie
  • 4 posts

Posted 31 May 2010 - 01:07 AM

Not too sure what transfer case you have, but I have an 03 silverado pickup and my transfer case started to leak too. Apparently on a certain model transfer case, there is an oil pump up inside there and a small clip sometimes works its way loose and over time will wear an actual very small pinhole in the side of the case. It usually happens on the tailshaft of the transfer case, way up on the side almost to the top on the passenger side. The dealer wanted $900 to fix mine, said he would have to replace the whole back half of the case. I took it home, located the hole with a magnifying glass, cleaned it up REAL good and took clear RTV silicone and sealed it up. The dealer told me it would never work, its been 50,000 miles and I have yet to see it leak again. Hope that helps.


Great m this is good to know . Now I have read if this is the case it does not drip on the ground , mine does. Did yours drip visably on the ground when the truck was parked ?


The case usually won't drip noticeably. The leak is very small and is usually detected when they notice fluid all over the case, or when the case completely fails due to a lack of fluid. There's no way the pump rub hole would spray fluid. Let alone spray it enough to get it on a window. The pump rub hole is TINY.

. Drip is noticable if the truck is parked for any length of time . So since the seal has been replaced twice and it still leaks and this does not fit the pattern of the hole then what might be another answer ? The last mechanic mentioned a small brass bushing he said had some slight wear on it when he was replacing the seal , could this be it ?

#9 pm26

pm26

    Senior Enthusiast

  • Member
  • 6,252 posts
  • Location:Florida
  • Gender:Male

Posted 31 May 2010 - 06:18 AM

I thought this problem was exclusive to HD trucks. I guess not. Has GM fixed this issue in later models? Somebody please give me a positive answer on this.

#10 sonjaab

sonjaab

    Member

  • Member
  • 2,153 posts
  • Location:syracuse ny
  • Gender:Male

Posted 31 May 2010 - 08:30 AM

The "pump rub" issue effects BOTH the 1500 and 2500 models judging from posts
here and elsewhwere and some folks opinions to the contrary.
Posted Image
Alexandria Bay NY & Syracuse NY
Daytona Beach FL

#11 thearborbarber

thearborbarber

    Enthusiast

  • Member
  • 481 posts
  • Location:SoDak
  • Gender:Male

Posted 31 May 2010 - 08:48 AM

Here's how I fixed mine on my 2004;

http://www.kennedydi...ubCategory2=135

Replace the case half and add the case saver and never deal with it again. My mechanic did it in a morning.

Edited by thearborbarber, 31 May 2010 - 08:50 AM.

2009 GMC Sierra 1500
1999 Chevy Camaro Z28 (Mr. Hyde)
2004 Honda Civic (Dr. Jeckel)

#12 spurshot

spurshot

    Senior Enthusiast

  • Member
  • 2,993 posts
  • Location:SoCalif
  • Gender:Male

Posted 31 May 2010 - 10:20 AM

The case wear from the failed oilpump clip (wear guard) is common. When I pulled my xfer case I replaced the pump and put in a case saver aftermarket kit, along with a new pump. I did get a massive oil leak a month later. It was the front seal which had been put in slightly crooked and allowed it to leak when parked pointed frontend downhill in my driveway. What a mess.




2014 Sierra SLT All Terrain 5.3 Crew 6 1/2 ft bed, 305/60-18 Cooper ST Maxx, 1 1/2" level, 5000k Morimoto HID, 4 Baja Designs SII LED lights, Bushwacker flares

2008 Silverado 1500 VMax Crew 4x4 LTZ, NHT


#13 pm26

pm26

    Senior Enthusiast

  • Member
  • 6,252 posts
  • Location:Florida
  • Gender:Male

Posted 01 June 2010 - 03:01 PM

Should I take some preventive action to prevent transfer case damage on my 2006 truck? What would be required?

#14 BrockwayMT

BrockwayMT

    Enthusiast

  • Member
  • 222 posts
  • Location:Syracuse, NY

Posted 05 June 2010 - 08:09 PM

Should I take some preventive action to prevent transfer case damage on my 2006 truck? What would be required?


Not much you can do short of taking the t/c apart to install an anti rattle plate. Just keep an eye on it as the leak develops slowly.

I don't know if the pump rub was an issue in the NV149 (escalade 1 speed) but since it has an oil pump in the same spot it seems possible. The NAPA seal shouldn't be a problem but I'd check the slip yoke for grooving. If its badly grooved or pitted it should be replaced. Around $100 part I think.
