Changing Rotors....


  • Please log in to reply
18 replies to this topic

#1 white07gmc

white07gmc

    Enthusiast

  • Member
  • 238 posts
  • Location:St. Augustine Florida
  • Gender:Male

Posted 02 June 2010 - 07:44 AM

What steps do I need to take to change the rotors on my Truck? 07 Sierra. I've done it before on imports just never on a Truck.

Posted Image


Kenwood DNX 7100 / Kenwood Bluetooth / Kenwood Backup Camera / 2 Kicker 10" CVR's / Alpine MRP M350 / 8000k HID Headlights / 8000k HID Fog Lights / Pace Edwards JackRabbit W/ Explorer Rails / 2x Sprocket Rocket Racks / Load Warrior Basket / Passport Sr7 With Laser Shifters / Hypertech Max Energy


#2 Chris

Chris

    My life is a progress bar

  • Moderator
  • 11,013 posts
  • Name:Chris
  • Location:Bakersfield, CA
  • Gender:Male
  • Drives:2004 GMC Sierra

Posted 02 June 2010 - 08:39 AM

bout the same. id have to look at mine but im 2200 miles away from it. i believe after you pull the wheel off, pull your caliper and pads. then there should be a cap over your wheel bearing. pry that off, dont damage it. then there is a cotter pin through a nut. pull out the pin and remove the nut. wheel bering should come out and the rotor should come off the spindle. when you reinstall repack the bearing with grease

2004 GMC SIERRA 1500 EXTENDED CAB SHORT BED, DARK SPIRAL GRAY METALLIC, LQ9 6.0 LITER V-8, TUNED BY BLACK BEAR PERFORMANCE, 2.5" LEVEL, 2500HD REAR LEAFS, FLUIDYNE THERM-HX TRANS COOLER, CHROME SILVERADO SS WHEELS, VOLANT INTAKE, CORSA SPORT, 05+ E-FANS, ESCALADE GAUGE BEZEL ON SS GAUGES, DC POWER 300 AMP ALTERNATOR

BUILD: http://www.gm-trucks...formance-build/


#3 bossier62guy

bossier62guy

    Senior Enthusiast

  • Member
  • 1,656 posts
  • Name:John
  • Location:Zachary, LA
  • Gender:Male
  • Drives:2002 Silverado Z-71

Posted 02 June 2010 - 08:42 AM

bout the same. id have to look at mine but im 2200 miles away from it. i believe after you pull the wheel off, pull your caliper and pads. then there should be a cap over your wheel bearing. pry that off, dont damage it. then there is a cotter pin through a nut. pull out the pin and remove the nut. wheel bering should come out and the rotor should come off the spindle. when you reinstall repack the bearing with grease


If that's what you believe than I suggest you obtain a service manual :cool:

#4 kawtoy_77

kawtoy_77

    Enthusiast

  • Member
  • 911 posts
  • Location:Elliott, IL
  • Gender:Male

Posted 02 June 2010 - 08:47 AM

:cool: funny.... thats the way the older rmodels were done though. make sure to re-pack the wheel bearings!

Edited by kawtoy_77, 02 June 2010 - 08:49 AM.

Never send a truck, to do a SIERRA's job....
1985 GMC C1500 High Sierra (SCLB)
5.0, headers, duals, Thrush glasspacks, K&N air filter, Edelbrock pro cleaner 14", AR-767 wheels, non-functional hood scoop, and alot of stickers in the back window...SOLD

http://www.gm-trucks...?...em&CID=2341

2007 GMC Sierra (SCLB)
5.3L Flex motor, 2wd, 265/70/17 Hankook DynaPro ATM RF10's, AVS vent guards
http://www.gm-trucks...?...em&CID=2340

www.ridingillini.com (local motorcycle forum) Champaign/Urbana Area

#5 Chris

Chris

    My life is a progress bar

  • Moderator
  • 11,013 posts
  • Name:Chris
  • Location:Bakersfield, CA
  • Gender:Male
  • Drives:2004 GMC Sierra

Posted 02 June 2010 - 08:50 AM

i havent changed them on my truck yet. i have on my 76 firebird, 87 thunderbird turbo coupe, 89 s-10 and my 92 integra., so im talking out my ass. tryin to help a lil bit though

2004 GMC SIERRA 1500 EXTENDED CAB SHORT BED, DARK SPIRAL GRAY METALLIC, LQ9 6.0 LITER V-8, TUNED BY BLACK BEAR PERFORMANCE, 2.5" LEVEL, 2500HD REAR LEAFS, FLUIDYNE THERM-HX TRANS COOLER, CHROME SILVERADO SS WHEELS, VOLANT INTAKE, CORSA SPORT, 05+ E-FANS, ESCALADE GAUGE BEZEL ON SS GAUGES, DC POWER 300 AMP ALTERNATOR

BUILD: http://www.gm-trucks...formance-build/


#6 bossier62guy

bossier62guy

    Senior Enthusiast

  • Member
  • 1,656 posts
  • Name:John
  • Location:Zachary, LA
  • Gender:Male
  • Drives:2002 Silverado Z-71

Posted 02 June 2010 - 09:15 AM

i havent changed them on my truck yet. i have on my 76 firebird, 87 thunderbird turbo coupe, 89 s-10 and my 92 integra., so im talking out my ass. tryin to help a lil bit though


It's a hell of a lot easier now....but there are some bolts that require thread locking compound and of course you need to know the torque values for the caliper bolts and the caliper bracket bolts. There are no bearings to worry about packing.

#7 kawtoy_77

kawtoy_77

    Enthusiast

  • Member
  • 911 posts
  • Location:Elliott, IL
  • Gender:Male

Posted 02 June 2010 - 10:50 AM

not even on the 2wd?! I thought the bearings ran inside the rotor assy of the 2wd's....
Never send a truck, to do a SIERRA's job....
1985 GMC C1500 High Sierra (SCLB)
5.0, headers, duals, Thrush glasspacks, K&N air filter, Edelbrock pro cleaner 14", AR-767 wheels, non-functional hood scoop, and alot of stickers in the back window...SOLD

http://www.gm-trucks...?...em&CID=2341

2007 GMC Sierra (SCLB)
5.3L Flex motor, 2wd, 265/70/17 Hankook DynaPro ATM RF10's, AVS vent guards
http://www.gm-trucks...?...em&CID=2340

www.ridingillini.com (local motorcycle forum) Champaign/Urbana Area

#8 Willshire

Willshire

    Enthusiast

  • Member
  • 184 posts
  • Location:Harriston Ontario Canada
  • Gender:Male

Posted 02 June 2010 - 10:59 AM

Not on the new stuff my 95 had $30 wheel bearings on the front that you had to pack but the new ones are 150-200 bucks because they are a sealed unit with the wheel speed sensor all in one. When it starts to howl be prepared to fork out the bucks. 3 points require the bolts to be removed... the wheel nuts, caliper to bracket bolts and caliper bracket bolts. I believe the caliper bracket bolts will be a high torque when you put them back on. Aluminum wheels to 100 ft/lbs. With minor experience should be able to complete both sides in less than 2 hours
2008 GMC Sierra SLE Crew Power Slot Rotors w/ Hawk Ceramics. Blackbear tune. IBEW LU 804
1964 Pontiac Grand Prix

#9 Amtz.Zero

Amtz.Zero

    ^^My reaction when I saw my truck for the first time.^^

  • Member
  • 976 posts
  • Location:Moreno Valley, California
  • Gender:Male

Posted 02 June 2010 - 11:32 AM

It's easy. You take off the wheel, then take off the calipers (the bolts are REALLY tight) then hit the old rotor with a rubber mallet a little and it comes right off. If there's any little lock washers on the lug nut bolts, just cut them off, you don't need them anymore. Then install the new rotors and put the calipers and wheels back on. It's really simple.
Posted Image 2004 GMC Sierra
4.8L V8- Flowmaster Super 40- GMT900 Yukon wheels

>>>BlackBear Tuned>>>

#10 pm26

pm26

    Senior Enthusiast

  • Member
  • 6,378 posts
  • Location:Florida
  • Gender:Male

Posted 02 June 2010 - 12:34 PM

A couple of comments:

1. New rotors are almost always coated with rust preventive compound of some type or they are oiled. Use acetone or brake cleaner to clean and degr3ease both sides of the new rotor before you install it. Otherwise you will track the oil or rustproofing spray into your brake pads.

2. Never let the calipers hang by the brake rubber hose. Make a caliper hanger from a piece of stiff wire, such as a wire coathanger, and bend it into an "S" shape and suspend the caliper securely from the coil spring while replacing the rotors.

#11 tanked_darren

tanked_darren

    Industrial Mechanic

  • Member
  • 2,334 posts
  • Location:Canada
  • Gender:Male
  • Drives:2007 GMC SIERRA, 2001 PONTIAC SUNFIRE

Posted 02 June 2010 - 01:12 PM

Is it newer style or classic? 2wd or 4wd?

On my 2007 newer style 2wd all I had to do was take the calipers off and then there was one torx head screw holding the rotor on, near the hub? They just slid off after that!
2007 GMT-900 GMC 1500 W/T 4.8L V-8 2wd auto 4L60E, 3.23 gear ratio
Reg. Cab, 6'6" Box, BLACK
Added myself: GM fog light kit, DIC panel, OGM-1, Camera Source Back-up Cam, Sirius dock.
Added otherwise: Leer Canopy. Linex bedliner+over-rail.
2001 Pontiac Sunfire 4-door, 2.2L OHV, 4T40e, Kenwood Excelon 9990HD, Sirius dock, Bass Car! Gas saver for work as well.

#12 kawtoy_77

kawtoy_77

    Enthusiast

  • Member
  • 911 posts
  • Location:Elliott, IL
  • Gender:Male

Posted 02 June 2010 - 01:41 PM

Not on the new stuff my 95 had $30 wheel bearings on the front that you had to pack but the new ones are 150-200 bucks because they are a sealed unit with the wheel speed sensor all in one. When it starts to howl be prepared to fork out the bucks. 3 points require the bolts to be removed... the wheel nuts, caliper to bracket bolts and caliper bracket bolts. I believe the caliper bracket bolts will be a high torque when you put them back on. Aluminum wheels to 100 ft/lbs. With minor experience should be able to complete both sides in less than 2 hours

GM and the rest FORD, and Dodge can't help but make things more expensive to fix, and more of a PITA to get to/remove can they!? :flag: :mad: :cool: just about like sealed unit U-joints...WORTHLESS.
Never send a truck, to do a SIERRA's job....
1985 GMC C1500 High Sierra (SCLB)
5.0, headers, duals, Thrush glasspacks, K&N air filter, Edelbrock pro cleaner 14", AR-767 wheels, non-functional hood scoop, and alot of stickers in the back window...SOLD

http://www.gm-trucks...?...em&CID=2341

2007 GMC Sierra (SCLB)
5.3L Flex motor, 2wd, 265/70/17 Hankook DynaPro ATM RF10's, AVS vent guards
http://www.gm-trucks...?...em&CID=2340

www.ridingillini.com (local motorcycle forum) Champaign/Urbana Area

#13 kawtoy_77

kawtoy_77

    Enthusiast

  • Member
  • 911 posts
  • Location:Elliott, IL
  • Gender:Male

Posted 02 June 2010 - 01:42 PM

Is it newer style or classic? 2wd or 4wd?

On my 2007 newer style 2wd all I had to do was take the calipers off and then there was one torx head screw holding the rotor on, near the hub? They just slid off after that!

what size torx is it?
Never send a truck, to do a SIERRA's job....
1985 GMC C1500 High Sierra (SCLB)
5.0, headers, duals, Thrush glasspacks, K&N air filter, Edelbrock pro cleaner 14", AR-767 wheels, non-functional hood scoop, and alot of stickers in the back window...SOLD

http://www.gm-trucks...?...em&CID=2341

2007 GMC Sierra (SCLB)
5.3L Flex motor, 2wd, 265/70/17 Hankook DynaPro ATM RF10's, AVS vent guards
http://www.gm-trucks...?...em&CID=2340

www.ridingillini.com (local motorcycle forum) Champaign/Urbana Area

#14 bossier62guy

bossier62guy

    Senior Enthusiast

  • Member
  • 1,656 posts
  • Name:John
  • Location:Zachary, LA
  • Gender:Male
  • Drives:2002 Silverado Z-71

Posted 02 June 2010 - 02:05 PM

Is it newer style or classic? 2wd or 4wd?

On my 2007 newer style 2wd all I had to do was take the calipers off and then there was one torx head screw holding the rotor on, near the hub? They just slid off after that!

what size torx is it?


If it's like the 800 series it's a T55...btw, the caliper bracket bolts require lock tite and are torqued up in the 120 lb ft range....mine were 121, not sure about yours.

Edited by bossier62guy, 02 June 2010 - 02:06 PM.


#15 DFWSierra

DFWSierra

    Enthusiast

  • Member
  • 72 posts
  • Location:Fort Worth, TX
  • Gender:Male

Posted 03 June 2010 - 03:16 PM

I need to change my rotors and pads also because of deep grooves and vibration under braking. I didnt want to just turn the crap factory rotors so I bought some powerlsots and hawk pads.

I have checked out the videos on Wonder How To
It seems pretty straight forward I guess if you don't run into any problems.

Also is it necessary to bleed the brakes? Cant you depress the piston back in without opening the bleeder valve?
Posted Image

2007 GMC Sierra SLE CC 5.3- Black Leather Six Seater
Performance - Airaid MIT, K&N Filter, Borla ProXS, Powerslot Rotors, Hawk Pads, Vette Servo, Black Bear Tune
Appearance - LED Tail Lights, 2" Drop Shackles, Undercover Tonneua
