S15 Gmc Truck ..windshield Wipers Stop Working After A While


  • Please log in to reply
9 replies to this topic

#1 VVV

VVV

    Enthusiast

  • Member
  • 7 posts

Posted 28 September 2011 - 12:05 PM

Suddenly it stops working in this S15 truck and start again after a while on its own...

what should I check ?

#2 GMcarnut

GMcarnut

    Enthusiast

  • Member
  • 28 posts

Posted 28 September 2011 - 05:26 PM

Hello,

I would advise replacing the windshield wiper motors because they are the most likely cause for non-operational wipers. For your convenience, here is the procedure for replacing the wiper motor :dunno:


1) Disconnect the negative battery cable.

2) Remove the wiper arms from the linkage so the cowl may be removed.

3) Remove the cowl vent grille and screen. On early model vehicles, the a windshield washer hose may be connected to a hard plastic fitting located under the cowl grille. If the hose connection is very tight it may make removing the cowl grille difficult. Take your time if difficulty is encountered, if possible, reach underneath the grille to disconnect the hose from the fitting.

4) Loosen but DO NOT remove the nuts which hold the drive link to the motor crank arm. Detach the drive link from the crank arm.

5) Remove the transmission linkage-to-cowl retaining screws, then carefully remove the linkage through the top of the cowl.

To install:

1) Carefully guide the linkage assembly through the opening in the top of the cowl.

2) Secure the transmission linkage using the retainers. Tighten the fasteners securely, but do not over tighten them.

3) Position the drive link socket onto the crank arm ball of the wiper motor assembly. Evenly tighten the socket nuts to secure the connection.

4) Install the cowl vent grille and screen. On vehicles equipped with a plastic fitting attached to the cowl grille, the washer hose should be connected as the grille is positioned. Make sure the hose is not pinched or damaged as the grille is fastened.

5) Install the wiper arm and blade assemblies to the transmission linkage.

6) Connect the negative battery cable and verify proper wiper operation.

Posted Image
*diagram courtesy of gmpartsgiant.com

#3 VVV

VVV

    Enthusiast

  • Member
  • 7 posts

Posted 28 September 2011 - 08:58 PM

Hello,

I would advise replacing the windshield wiper motors because they are the most likely cause for non-operational wipers. For your convenience, here is the procedure for replacing the wiper motor :lol:


1) Disconnect the negative battery cable.

2) Remove the wiper arms from the linkage so the cowl may be removed.

3) Remove the cowl vent grille and screen. On early model vehicles, the a windshield washer hose may be connected to a hard plastic fitting located under the cowl grille. If the hose connection is very tight it may make removing the cowl grille difficult. Take your time if difficulty is encountered, if possible, reach underneath the grille to disconnect the hose from the fitting.

4) Loosen but DO NOT remove the nuts which hold the drive link to the motor crank arm. Detach the drive link from the crank arm.

5) Remove the transmission linkage-to-cowl retaining screws, then carefully remove the linkage through the top of the cowl.

To install:

1) Carefully guide the linkage assembly through the opening in the top of the cowl.

2) Secure the transmission linkage using the retainers. Tighten the fasteners securely, but do not over tighten them.

3) Position the drive link socket onto the crank arm ball of the wiper motor assembly. Evenly tighten the socket nuts to secure the connection.

4) Install the cowl vent grille and screen. On vehicles equipped with a plastic fitting attached to the cowl grille, the washer hose should be connected as the grille is positioned. Make sure the hose is not pinched or damaged as the grille is fastened.

5) Install the wiper arm and blade assemblies to the transmission linkage.

6) Connect the negative battery cable and verify proper wiper operation.

Posted Image
*diagram courtesy of gmpartsgiant.com


Thanks but before I do all this...some one said...circuit board on wiper motor goes bad and you should change just that board ...what do you think?

#4 Bagger97

Bagger97

    Enthusiast

  • Member
  • 11 posts
  • Location:Sahuarita, AZ
  • Gender:Male
  • Drives:2011 Sierra CC, 2012 Terrain

Posted 23 February 2012 - 08:53 PM

GM had a recall years ago to replace the circuit board. Might check on that first.
2011 Sierra Crew Cab
2012 GMC Terrain

#5 07blackz71

07blackz71

    Senior Enthusiast

  • Member
  • 1,953 posts
  • Location:Cedarburg, WI
  • Gender:Male
  • Drives:2013 Silverado CrewCab LTZ 4x4 6.2L

Posted 23 February 2012 - 10:15 PM

Yes I would do the circuit board first. I had that issue with my 96 s10 and that fixed it.

Edited by 07blackz71, 23 February 2012 - 10:16 PM.

2013 Silverado Crew Cab LTZ 4X4  6.2L,  black
Mods: AFE intake, 2" RC leveling kit,, 20" MB Gunner 6 wheels, 275/60/20 Cooper Zeon LTZ, ARE Z-series cap

2012 Chevy Equinox lt2 Ashen Gray Metallic, 35% tint.


#6 CRTurboGuy

CRTurboGuy

    Enthusiast

  • Member
  • 40 posts
  • Name:Josh
  • Location:Cedar Rapids, IA
  • Gender:Male
  • Drives:Too many to list

Posted 23 February 2012 - 10:57 PM

I've had the same problem in my 91, and a new motor and new switch didn't fix it. I think it's an issue w/ a bad ground somewhere, but haven't managed to track it down.

--JOsh
Vehicle Wh*re:
2011 GMC Sierra SLE Crew - DDM 6k HID's, Weathertech front/rear, Truxedo cover | 2007 Honda Fit Sport
1995 Chevy 3500 Work Truck | 1991 GMC S-15 Jimmy Plow Truck | 1964 Lotus Seven Replica - R1 powered
1990 Yamaha XT600 | 1983 Yamaha CV80
Posted Image

#7 2kflhr

2kflhr

    Enthusiast

  • Member
  • 254 posts
  • Gender:Male

Posted 23 November 2012 - 07:56 PM

I had this same problem on my '91 Yukon when it was 3-4 years old and replaced the board for something like $40 bucks (back then) at my cost from the dealer. it did it again several years later so I decided to pull the board and look at the solders closely with a very strong magnifying glass. What Ifound was several cracked solder joints. I resoldered them and never had another problem again. Just recently I had this same thing happen on my '99 Yukon. Again, it was a bad solder on the circuit board, They faulty ones are typically the first 3-4 nearest the plug in my experience. Try that and it may save you some money.

"Significant problems cannot be resolved with the same level of inteligence that created them"

'10 Escalade

'97 Camaro SS





#8 brainpause

brainpause

    Enthusiast

  • Member
  • 595 posts
  • Name:Larry
  • Location:Franklin, Tennessee
  • Gender:Male
  • Drives:2006 Silverado CC Z71

Posted 23 November 2012 - 11:21 PM

Had a 95 S10 that just about got me killed with this issue. I was going along with traffic about 65 miles an hour in a construction zone with a hard rain. Concrete barriers on both sides. Windshield wipers decided to stop working. Scared the bejeebies out of me. I decided to contact the National Transportation Safety Board (NTSB). I had to pay to get it fixed immediately, but after the recall, I was reimbursed by General Motors.

so, check for a recall on your vehicle.

Larry
Holly
Jessie Grace
Jamie Lyn
2006 Silverado CC Z71, 5.3L 3.42
Wait4mePerformance
Aeroforce Interceptor Pillar Gauge
Hayden Transmission Cooler
Putnam XDR Class V hitch



#9 8.1HD/ALLISON

8.1HD/ALLISON

    Senior Truck Tweaker

  • Moderator
  • 2,663 posts
  • Name:Matt
  • Location:Indiana
  • Gender:Male
  • Drives:04 K2500HD

Posted 24 November 2012 - 06:31 AM

A lot of times it is the circuit board. Usually when they quit you can tap on wiper motor with a screwdriver handle and they will start right back up.

You want fuel economy? Buy a Prius.... I have a big block!
------------------------------------------------------------------------------------------------------
2004 Chevy Silverado K2500 HD CCLB, 8.1L/Allison, 285/75R16 Goodyear Duratracs,
B&W hitch, Whelen 6 channel strobe lights, Soundoff Signal Mini Light Bar,
Dual Flowmaster Super 44's, BlackBear Tuned, Too much to list,





#10 ZachM1

ZachM1

    Enthusiast

  • Member
  • 25 posts
  • Name:ZachM
  • Location:Florida Panhandle
  • Gender:Male
  • Drives:2007 Z71 1500

Posted 24 November 2012 - 11:16 AM

I've fixed many full size and s10 variants around your model year just by pulling the black cover (held by several torx screws), soldering 2 circuit joints just inside the plug side of the board, and reinstalling the cover.

Sent from my Galaxy Nexus using Tapatalk 2
