Contributing Writer, GM-Trucks.com
General Motors announced today it will build the new 3.0-liter Duramax diesel engine in Flint Michigan. The company will invest $263 million to prepare the line for the new engine build. Flint Engine, as the plant is called, presently builds small four-cylinder gasoline engines for GM vehicles, but has produced Duramax engines in the past.
“The next-generation Silverado builds on the success of our current models, many of which are produced here in Flint. We are proud to expand the industry-leading diesel portfolio here in Vehicle City,” said John Urbanic, Flint Engine Operations plant manager.
The 2.8-liter Duramax engine that GM uses in the Colorado and Canyon are built in Rayong, Thailand. This new move by GM to bring the Durmax production stateside and invest heavily in a plant to build the engine, leads us to speculate that the 3.0-liter engine will likely be used in more vehicles than just the Silverado. The GMC Sierra will get the engine, and possibly GM’s large SUVs. It may even supplant the 2.8-liter engine now used in the Colorado and Canyon at some future point.
Hey Everyone. I’ve been looking at buying a diesel 6.6 L duramax denali GMC automatic transmission. Both of the 2014 models in separate cities I’ve looked over have two, 3/8 or 1/2 inch holes drilled on the left side of the steering wheel in the dash. I can tell these are not manufacturer drilled, and was wondering why I have seen this on that model twice. At first I thought to mount the trailer brake controller, but the holes are way bigger than necessary for screw mounting. The holes are big enough they are very noticeable, an ink pen could easily pass through. So question 1: why drill these two holes? Both models I’ve looked at have a trailer towing feature engaged by pushing the end of the shifter on the right side of steering wheel inwards. Would that not mean this model also comes equipped with trailer brake controller? I’m concerned the previous owners removed something I will need for trailer towing or some other feature of interest. I can see the gooseneck mount, or trailer hitch and the 7 way round plug, so I’m baffled on why these holes are there in the dash. Thanks in advance.
Ford Drops First-Ever F-150 Diesel – Targets 30 MPG & Class-Leading Towing - Video, Images, Specs, TimingBy Gorehamj
Contributing Writer, GM-Trucks.com
Ford announced a sixth engine option for the F-150 line this week. The new engine is a 3.0-liter, V6 “Power Stroke” turbo diesel. The new engine will produce its peak torque of 440 ft-lbs at 1,750 RPM. To make the most of that twist, Ford has mated it to a diesel-specific SelectShift 10-speed automatic transmission which can shift non-sequentially. In other words, it can skip over gears to find the right one for the circumstances. Ford’s aim is to produce the best towing combination in the F-150’s class in terms of efficiency and drivability.
“For every truck owner who wants strong fuel economy while they tow and haul, we offer a new 3.0-liter Power Stroke V6 engine that dreams are made of,” said Dave Filipe, vice president global powertrain engineering. “The more you tow and the longer you haul, the more you’ll appreciate its class-leading towing and payload capacity and how efficient it is at the pump.”
The new 3-liter Power Stroke diesel has just 250 hp, but will be able to tow up to 11,400 pounds and has a 2,020-pound payload capacity. Ford says this combination makes the new F-150 the best-in-class hauler. Going further, Ford says that this new drivetrain will be the best hauler in the most severe conditions. Rather than an electric cooling fan, Ford has opted for a premium mechanical engine-driven fan plus dual radiator shutters for improved high temperature, high-altitude performance. “We know that competing diesels with electric cooling fans have to dial back on power under extreme heat and altitude, so we decided on a viscous-controlled mechanical fan that has the capacity to move much more air across the radiator and intercooler in extreme conditions,” said David Ives, Ford diesel engine technical specialist. “This gives F-150 Power Stroke owners more power and more passing capability in harsh conditions.” Ford says that in moderate driving and towing conditions, the F-150 engine control system will back off the fan load through a viscous coupler and close the radiator shutters for improved aerodynamic efficiency and reduced parasitic engine loss.
Ford’s extensive experience with boosted engines shows in the new engine’s design. With a focus on reducing turbo lag, Ford incorporated a high-efficiency variable-geometry turbocharger. Fuel injection is via a common-rail fuel injection system with a 29,000 pounds per square inch injection calibration. Ford promises smoother, quieter operation and reduced emissions. Borrowing from the new 2.7-liter turbocharged gasoline engine in its trucks, the new Ford V6 diesel uses a compacted-graphite iron block material and has a forged-steel crank. Other features of the new engine include dual fuel filters, a cast-aluminum oil pan, and a two-stage oil pump.
Ford says the new 3-liter turbodiesel F-150 can be ordered in either rear-wheel drive or 4X4 in the following configurations starting this month:
- 2018 F-150 Lariat, King Ranch and Platinum edition SuperCrew trucks with either a 5.5-foot or 6.5-foot bed configuration, and SuperCab trucks with a 6.5-foot bed configuration.
Commercial Fleet Customers:
- All F-150 trim levels with SuperCrew 5.5-foot or 6.5-foot bed configurations and SuperCab trucks with a 6.5 foot bed.
Alright so I have this idea and I don't know if its possible or not. Camaro's have an option where you can have illuminated door panels, I would like to do something similar in 2017 silverado. I have already added interior door piping that matches the exterior color of the truck. I would like to take that same concept but use EL wire instead of the silver piping to create illuminated door panels. I dont want to do too much but I think it would add a little more to the interior and be different.
My thoughts are to get some EL wire with the welting attached to it and place it where the current piping is. But the part I am on the fence about would be what to wire it to. These doors have the lights in the handles that dim with the main dimmer for all of the dash. I was wondering if it could be wired into the circuit that way it would be the same brightness as all the other illumination on the dash. But if you have ever messed with EL wire before, it runs of AC current. You need a 12v driver for them to operate off of a 12v system.
Would it be better to run 1 inverter that would power all 4 doors and then have to run the wire through the whole cab or purchase 4 smaller inverters and place them in behind the door panels. If I was to only use 1 inverter I could possibly connect it to the main dimmer switch instead of the doors circuit. But these lights should not pull alot of current so I'm unsure which would be the best way.
In these picture on my door panel the silver line coming from where the window switch is, is the piping. Thats where the EL wire would go. If i used 1 driver i would need to use a 4 way splitter to go to each door. I have attched a picture of multiple drivers, these things come in all different sizes. The driver i would use if I did 4 different inverters is used to power up to 2 meters of wire. The amount in would be powering would be way shorter then that and the inverter is about 1 inch by 2 inch, so very small. The 1 big inverter option is pretty good size and also is rated to power up to 15 meters.
This should be relatively cheap
4 drivers = $28
EL wire= $15
so about $60
I believe I have found a color that matches the chevy color, the aqua color is pretty dang close if not identical. For the sierra guys, they make red as well.
You would need connectors so you can cut the EL wire to length for the door, It is pretty easy to wire the connector to the EL wire. Most use a 2 pin JST wire connection and you can get a kit with 10 connectors and heat shrink for like $10. I am just wondering if anybody has thought of this or done this and how. If you have any experience with EL wire please chime in.
