2002 G80 - Locking or Limited Slip


  • Please log in to reply
11 replies to this topic

#1 Dave in Mpls

Dave in Mpls

    Enthusiast

  • Member
  • 162 posts

Posted 30 March 2005 - 08:54 PM

After reading several posts on the topic, I'm now more confused than ever!!

I have a 2002 'Burb LT with an RPO code G80. According to the 2002 RPOs on this site, the 2002 G80 is "Axel Positraction Limited Slip", whereas the 2003 G80 is listed as "Differential, Locking, Heavy-duty, rear".

My question - is the 2002 G80 a locking or limited slip differential and, more importantly, can I run Mobil 1 gear lube in it, and do I need to run the additive?

Thanks!

#2 Jacqson

Jacqson

    Enthusiast

  • Member
  • 447 posts
  • Location:North Vancouver BC
  • Gender:Male
  • Drives:2011 Chevy Silverado 3500HD

Posted 30 March 2005 - 10:05 PM

After reading several posts on the topic, I'm now more confused than ever!!

I have a 2002 'Burb LT with an RPO code G80.  According to the 2002 RPOs on this site, the 2002 G80 is "Axel Positraction Limited Slip", whereas the 2003 G80 is listed as "Differential, Locking, Heavy-duty, rear".

My question - is the 2002 G80 a locking or limited slip differential and, more importantly, can I run Mobil 1 gear lube in it, and do I need to run the additive?

Thanks!

<{POST_SNAPBACK}>


The G80 is a locking differential, and is the Mobil 1 you want to use a synthetic or regular gear oil? The recommended oil for the rear axle according to the GM Service Manual for your truck is a 75w-90 Synthetic (GM part#12378261 for the U.S. and Part#10953455 for Canada) or equivalent meeting GM specification No. 9986115. The Service Manual makes no mention of Limited Slip additive so I would say you do not need it unless you get chattering from the rear. :uhoh:
2011 Chevy Silverado 3500HD CCSB LTZ Dmax/Allison Taupe Gray Metallic, Lots of Goodies


SOLD-My loaded up 2002 2500 Suburban

#3 asilverblazer

asilverblazer

    The Red-Headed step child of the bunch.

  • Member
  • 3,636 posts
  • Location:Oklahoma City
  • Gender:Male

Posted 31 March 2005 - 09:18 AM

At first it will allow a 100rpm difference in each wheels speed (about), limited slip, at which point the locking mechanism will be activated, fully locking the rear wheels together with no difference in wheel speed allowed between them.
1955 Chevrolet 4400 1 1/2ton Stake Bed
2007 Chevrolet Silverado Extended Cab LT Z-71 5.3L 4x4 BLACK
Signal Mirrors, Chrome Covers, Chrome Door Handles, Painted Bow-Ties, Painted Mirror Housings, Painted Tailgate Handle Bezel, Chrome Tailgate Handle, Leveling Kit, Kenwood DDX616 Headunit, Infinity 6022i speakers powered by Alpine Amp, Alpine Subs powered by Alpine Amp, Tinted Windows, Tekonsha Prodigy Brake Controller, Dale Jr. Cannons, Dueler A/T Revos

Posted Image

#4 Butch 02 Denali

Butch 02 Denali

    Enthusiast

  • Member
  • 929 posts
  • Location:Middleton, MA
  • Gender:Male

Posted 31 March 2005 - 09:44 AM

The Eaton G80 is both a limited slip and a locker!

GM recommended synthetic lube has the additive in it already, that is why they say not to add any!

http://automotive.ea...ockingdiff.html

Edited by Butch 02 Denali, 31 March 2005 - 09:45 AM.

Butch 02 Sierra Denali
99 3500 w/350-4L80E
04 Avalanche 5.3
77 Vette, 408 SB blown and injected
2002 Pewter Sierra Denali DenaliTrucks
325HP 6.0 AWD with Quadrasteer
Wester's 91/93 Hot tune/Outlaw intake/Custom exhaust

#5 Kurt_T

Kurt_T

    Enthusiast

  • Member
  • 300 posts
  • Location:connecticut
  • Gender:Male

Posted 21 December 2010 - 09:37 PM

I also have an issue cause i have an 2001 2500HD with the 8.1 and 3.73s and my sticker in the glove box also says G80 but it says that the G80 is a Limited Slip when i look it up on the Code Chart? which is it really limited slip or locker?
Posted Image

#6 RyanbabZ71

RyanbabZ71

    Administrator

  • Senior Moderator
  • 18,557 posts
  • Name:Ryan
  • Location:Avon, Indiana
  • Gender:Male
  • Drives:2010 Chevy Silverado Crewcab Z71 6.2L

Posted 21 December 2010 - 09:52 PM

G80 = Differential Heavy Duty Automatic Locking Rear

This is what is on my 2000 Silverado, 2008 Tahoe, and 2010 Silverado build sheets

Ryan

2010 Silverado Crewcab 4wd Z71 6.2L V-8 (L9H) Flex Fuel 6 Speed Transmission Sheer Silver Metallic
2012 Camaro 2SS Convertible 6.2L V-8 (L99) Ashen Gray Metallic
My Garage: http://www.gm-trucks...gallery&user=56
Camaro Mods http://www.camaro5.c...ad.php?t=257256





#7 Kurt_T

Kurt_T

    Enthusiast

  • Member
  • 300 posts
  • Location:connecticut
  • Gender:Male

Posted 21 December 2010 - 10:14 PM

so then yeah i do have a Rear Locker? is what youre trying to say
Posted Image

#8 ChevyTech77

ChevyTech77

    GM Master Certified Technician

  • Member
  • 2,697 posts
  • Location:Michigan
  • Gender:Male
  • Drives:'11 Silverado ECSB L9H Z71

Posted 21 December 2010 - 10:48 PM

so then yeah i do have a Rear Locker? is what youre trying to say


Correct. All G80 RPO code trucks, with the exception of QS, are Eaton locking differentials.
99 to current take 75w90 synthetic gear oil with no limited slip additive.
Chevy tough.
Anytime baby!

Every screw up is an opportunity not to make another one.

#9 RyanbabZ71

RyanbabZ71

    Administrator

  • Senior Moderator
  • 18,557 posts
  • Name:Ryan
  • Location:Avon, Indiana
  • Gender:Male
  • Drives:2010 Chevy Silverado Crewcab Z71 6.2L

Posted 22 December 2010 - 05:06 AM

so then yeah i do have a Rear Locker? is what youre trying to say


Its not what I was trying to say its what was stated.

Ryan

2010 Silverado Crewcab 4wd Z71 6.2L V-8 (L9H) Flex Fuel 6 Speed Transmission Sheer Silver Metallic
2012 Camaro 2SS Convertible 6.2L V-8 (L99) Ashen Gray Metallic
My Garage: http://www.gm-trucks...gallery&user=56
Camaro Mods http://www.camaro5.c...ad.php?t=257256





#10 Kurt_T

Kurt_T

    Enthusiast

  • Member
  • 300 posts
  • Location:connecticut
  • Gender:Male

Posted 22 December 2010 - 08:49 AM

so then yeah i do have a Rear Locker? is what youre trying to say


Correct. All G80 RPO code trucks, with the exception of QS, are Eaton locking differentials.
99 to current take 75w90 synthetic gear oil with no limited slip additive.


thanks! did not know that, very helpful!
Posted Image

#11 snakedoctor

snakedoctor

    Senior Enthusiast

  • Member
  • 3,395 posts
  • Gender:Not Telling

Posted 22 December 2010 - 10:39 AM

See video...



#12 johnnyquick

johnnyquick

    Enthusiast

  • Member
  • 20 posts

Posted 02 January 2011 - 06:23 PM

and then read the comments these rear ends are notorious for blowing up when used as they are intended.

See video...
