Sonoma Trailer Wiring?


This topic has been archived. This means that you cannot reply to this topic.
5 replies to this topic

#1 daviddsims

daviddsims

    Enthusiast

  • Member
  • 54 posts

Posted 20 December 2007 - 01:29 PM

I just bought an 02 Sonoma from someone and noticed it doesnt have a plug to plug trailer lights into. Does anyone know how to add a plug? Thanks

#2 04z71steve

04z71steve

    Enthusiast

  • Member
  • 581 posts
  • Location:illinois
  • Gender:Male

Posted 20 December 2007 - 02:59 PM

I just bought an 02 Sonoma from someone and noticed it doesnt have a plug to plug trailer lights into. Does anyone know how to add a plug? Thanks


i'm pretty sure gm makes a harness that should have been in the glove box if the hitch was original equipment... but the old owner may have gotten rid of it... if not i'm sure somebody on here has the schematic to help u wire one up! you can get one of the plug style hitch plugs online on ebay for pretty cheap... i'm pretty sure those will come with a wiring schematic to help you install it..

good luck!
steve..
Posted Image

mods: cobra radar detector, midland cb, ss grill guard, ss nerf bars, geolander at+II's,lebra bed cover with custom lighting
tb crank, 10" Alpine type R, with 800 watt RF amp, 17" navibe gps, camo z71 stick, custom grill lights...
04 15oo z71 silverado extended cab
02! lt autride suburban
04 gmc safari
07 chevy express 2500
all american!!!

#3 wages999

wages999

    Enthusiast

  • Member
  • 224 posts
  • Location:Randolph, Ohio

Posted 21 December 2007 - 11:05 AM

You can buy aftermarket wiring harness that plugs into the existing wiring at any autoparts store. With the kit, you just have to unplug the wire connections behind the bumper and plug the wiring harness inbetween the two sides. I think the kit only has the 4-prong connector.

#4 Hooty

Hooty

    Enthusiast

  • Member
  • 28 posts
  • Location:Nova Scotia, Hurricane center of Canada

Posted 22 February 2008 - 07:32 AM

You can buy aftermarket wiring harness that plugs into the existing wiring at any autoparts store. With the kit, you just have to unplug the wire connections behind the bumper and plug the wiring harness inbetween the two sides. I think the kit only has the 4-prong connector.


I recently purchased a 2003 Sonoma that was not used as a tow vehicle, hence no hitch or wiring. I installed a hitch and purchased a "Trailer wiring adapter " connector from an autoparts supply company (Canadian Tire here in Canada) for $19.99. You can probably get it an one of the many parts outlets if you are in the USA (Pep Boys, NAPA, etc.)

The rear lights wiring harness runs along the driver's side frame rail and near the point where the bumper bolts to the frame, there is a weather tight connector. In the Navy we used to call these "Breakout Connectors". The "T" connector I bought fits into this connector.

It is a simple process to pull the connector apart, install the "T" to the feed from the front of the truck. Then plug the lighting harness into the other side of the "T" connector. It is specifically made to fit and it is weather proof with rubber seals just like the factory plugs and connectors. It is pre-wired with a 4 pin connector. I had to drill a 1/8 hole in the frame rail for the ground wire but that was the extent of the modifications to the truck. The whole job from start to finish took 10 minutes. Most of that time was spent trying to locate my cordless drill!

Hope this helps.

Cheers,

Hooty

#5 pj5454302

pj5454302

    Enthusiast

  • Member
  • 276 posts
  • Gender:Male

Posted 06 April 2008 - 05:04 PM

If the truck didnt come from the factory with the wiring you can get a harnes from a autoparts store and pug them into the tail light harnes.
Posted Image
2000 GMC Jimmy 2 dr 4.3 4x4 Z85
No precat and straight pipe |4300k HID converted Kc Daylighters| 4, 9 inch HID spot lights on the roof |Locked lifted and ready for the trails.
For pics click link http://www.cardomain...de/3800174Check it out

#6 daviddsims

daviddsims

    Enthusiast

  • Member
  • 54 posts

Posted 09 April 2008 - 03:28 PM

Yeah I bought a plug from an auto parts store and plugged it right in. Thanks everyone.
