In-dash 4wd Switch Replacement


  • Please log in to reply
22 replies to this topic

#1 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 08:23 AM

I've decided to remove and inspect the in-dash 4WD panel (pushbuttons). I've read a few threads that describe loose solder and if that is the problem, I intend to repair the switch using my soldering iron.

I read a step-by-step for a '99 that described pulling the surround from the center dash (after dropping the tilt wheel down and putting the shift selector in 'Low 1'). Then, popping the switch out of the dash.

What is the removal/install procedure for an '03?

2003 Silverado Z71 Ext Cab, 4WD
4.8L
Auto
Approx 58,000 miles

NOTE: I also just replaced the 4WD Actuator.

#2 Majorleaguebass

Majorleaguebass

    Senior Enthusiast

  • Member
  • 1,106 posts
  • Location:Texas
  • Gender:Male

Posted 25 September 2008 - 11:05 AM

if you are just trying to repalce the switch, it just pops out and they are 2 connectors going to the back of it, then you jusst plug it back in...i think that is what you are trying to get at?
2010 Chevy Tahoe Z71 4x4 Loaded

:SOLD: 2003 gmc sierra z71:6 inch Rough Country Lift:2 in Ready lift leveling kit w/ add a leafs:3 inch Performance Acessories Body Lift:Hid Headlamps,fogs (6000k) and corner lenses:APC led 3rd brake:37 inch Nitto Mud Grapplers:20" KMC Hoss Wheels:Escalade Door Handles:Probox (Under Seat):2- Jl Audio W1-v2 10" subs:Jl Audio e1200 amp:
Stinger Wiring:Flowmaster "Turn Down" Exhuast:
Rpm Performance Transmission (Stage V):Bushwacker Oem Fender Flares Painted:
Oem Painted Mirror Caps:Pro Comp Traction Bars:Detroit Locker:
Posted Image

#3 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 11:20 AM

if you are just trying to repalce the switch, it just pops out and they are 2 connectors going to the back of it, then you jusst plug it back in...i think that is what you are trying to get at?


Could you be more descriptive of the removal procedure for the switch panel? Do I have to pry it out with anything?

#4 Lincoln

Lincoln

    Enthusiast

  • Member
  • 492 posts
  • Location:Fort Worth, TX
  • Gender:Male

Posted 25 September 2008 - 11:22 AM

I think the 03 dash bezel comes off the same way it did in 99. Just lower the wheel all the way and pull the bezel straight back to get the clips to release (it does take a little twisting and turning to work the bezel out once the clips are released). The switch is held in with tabs. It's a 5 minute job to replace the switch.

Edited by Lincoln, 25 September 2008 - 11:39 AM.

08 GMC Sierra Denali - White/Black AWD, 20x9.5 BBS RD-Truck, 305/50/20 Terra Grapplers, 2" RC Level, V1 hardwired w/ remote display, debadged, 20% tint, Line-X Xtra, CMS Side box, wheel house liners, bed rail caps, Lockpick, Rostra Rear Cam, Raytel Televid5000 bluetooth (POS-removed), Clifford 50.5X 2-way alarm/remote start, Blinder M45, Vararam, Frontier-Gear Xtreme Bumper, "Dallas" Blackbear Tune.
99 Chevy Silverado LT Z71 ECSB - White/Graphite, lots of mods
97 Mercedes SL500 - Silver/Ash, weekend toy, 19" AMG replicas
03 Mercedes SL55 AMG - Silver/Charcoal Pano-roof - my dealership demo

#5 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 11:56 AM

Instructions accompanied by pictures make all of the difference:

2003-2006 GM Truck Cluster Removal



1. Apply the parking brake to prevent the vehicle from moving.

2. If equipped with an automatic transmission, move the shift lever all the way down to last gear (this will allow you room to remove the bezel).

3. Tilt the steering wheel to the full down position. You do not need to remove the steering wheel as seen in the image - "Picture 1" below.

4. Pull gently rearward on the corners of the bezel from the instrument panel (IP) assembly. There are no screws holding in place. See "Picture 1" below.

5. Remove the bezel.

NOTE: I stop here. I can get to the 'Transfer Case Control Switch' easily. For full cluster removal, continue...

6. Remove the (7mm hex head) screws that retain the Instrument Panel Cluster (IPC) to the I/P assembly. See "Picture 2" below.

7. Remove the IPC (2) from the vehicle by tilting the bottom of the cluster outward. See "Picture 3" below.

8. Disconnect the IPC harness (1) from the IPC by squezing in it's clamp tab and pulling moderately. See "Picture 3" below.

Picture 1: http://www.mrwhizard...ocs/ACF1738.gif


Picture 2: http://www.mrwhizard...er_removal2.gif


Picture 3: http://www.mrwhizard...ug_removal3.gif

At least with 'Picture 1' I knew where to 'start pulling' at the edges... I'd have chipped the bezel for sure where I thought the edges were. Bezel is hanging loose in the truck as I type this.

Edited by TedH, 25 September 2008 - 12:02 PM.


#6 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 12:11 PM

ok. Just got the switch assembly out... pry CAREFULLY at the top of the switch. There is a place to get a narrow screwdriver in at the top (that's what I used). prying gently, I was able to pull on the switch assembly and it popped out. I note there are four 'clips' on the four sides that hold the switch in place.

Now, I'm going to take the rear cover off the switch to see if I can inspect the solder inside...

stay tuned!

#7 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 12:23 PM

All of the soldered connections look fine... :puke:

I'll see about getting a replacement switch.

#8 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 12:26 PM

Do I have to re-install the 4WD switch to drive the truck? It was in 2Hi when I removed the switch. Do I need to pull a fuse (which one)?

#9 Majorleaguebass

Majorleaguebass

    Senior Enthusiast

  • Member
  • 1,106 posts
  • Location:Texas
  • Gender:Male

Posted 25 September 2008 - 12:28 PM

yea you can still drive the truck, it will not hurt a thing to drive it
2010 Chevy Tahoe Z71 4x4 Loaded

:SOLD: 2003 gmc sierra z71:6 inch Rough Country Lift:2 in Ready lift leveling kit w/ add a leafs:3 inch Performance Acessories Body Lift:Hid Headlamps,fogs (6000k) and corner lenses:APC led 3rd brake:37 inch Nitto Mud Grapplers:20" KMC Hoss Wheels:Escalade Door Handles:Probox (Under Seat):2- Jl Audio W1-v2 10" subs:Jl Audio e1200 amp:
Stinger Wiring:Flowmaster "Turn Down" Exhuast:
Rpm Performance Transmission (Stage V):Bushwacker Oem Fender Flares Painted:
Oem Painted Mirror Caps:Pro Comp Traction Bars:Detroit Locker:
Posted Image

#10 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 12:43 PM

Ordered 4WD Selector switch, part # 19168767 from gmpartsdirect.com today. $43.46 plus S&H.

#11 Majorleaguebass

Majorleaguebass

    Senior Enthusiast

  • Member
  • 1,106 posts
  • Location:Texas
  • Gender:Male

Posted 25 September 2008 - 12:44 PM

that should do it for you, did you overnight it, i wouldnt be able to stand for that hole in my dash? When i did mine, i ordered the switch way befor ei did it so i had it, i ever have a spare at the house just in case
2010 Chevy Tahoe Z71 4x4 Loaded

:SOLD: 2003 gmc sierra z71:6 inch Rough Country Lift:2 in Ready lift leveling kit w/ add a leafs:3 inch Performance Acessories Body Lift:Hid Headlamps,fogs (6000k) and corner lenses:APC led 3rd brake:37 inch Nitto Mud Grapplers:20" KMC Hoss Wheels:Escalade Door Handles:Probox (Under Seat):2- Jl Audio W1-v2 10" subs:Jl Audio e1200 amp:
Stinger Wiring:Flowmaster "Turn Down" Exhuast:
Rpm Performance Transmission (Stage V):Bushwacker Oem Fender Flares Painted:
Oem Painted Mirror Caps:Pro Comp Traction Bars:Detroit Locker:
Posted Image

#12 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 12:49 PM

Did I order wrong part #? I just checked and it says 99-02 Silverado. Mine has the black buttons... this has gray buttons.

#13 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 01:35 PM

After doing (the rest of) my homework:

GM PN's:
03-07 Silverado/Sierra 15136039, $50.56
99-02 Silverado/Sierra 15709327, $42.19

And, one that is really confusing and that I ordered in error:
99-02 Silverado/Sierra 19168767, $43.46

I've sent a note to gmpartsdirect.com requesting the order be cancelled... I hope they do as it is a non-returnable item.

Edited by TedH, 25 September 2008 - 01:36 PM.


#14 TedH

TedH

    Enthusiast

  • Member
  • 109 posts
  • Location:NW Arkansas
  • Gender:Male
  • Drives:2003 Silverado 4.8L Ext Cab Z71 Fire Red

Posted 25 September 2008 - 01:59 PM

I re-installed the old switch until the new arrives.

#15 Majorleaguebass

Majorleaguebass

    Senior Enthusiast

  • Member
  • 1,106 posts
  • Location:Texas
  • Gender:Male

Posted 25 September 2008 - 02:37 PM

yea they should cancel the order, the older switch doesnt work for the 03-07 trucks, plus you're right, its gray in color. if they do send it, stick it on ebay and order one from ebay
