Torsion Bar Adjustment For Plow


  • Please log in to reply
9 replies to this topic

#1 speedydog5

speedydog5

    Enthusiast

  • Member
  • 18 posts

Posted 30 December 2008 - 01:35 PM

I have a 2003 2500HD, just had plow put on,7-1/2 pro plow ultramount, should i have the torsion bars turned up to help out seems to bottem pretty easy, going up driveway, is this commen??? and how do i go about adjusting if i do? how much do i go

#2 DZRick

DZRick

    Enthusiast

  • Member
  • 74 posts
  • Location:ny

Posted 30 December 2008 - 07:45 PM

The plow guys would be the ones to ask,
http://www.plowsite.com/

I think it depends more on how much your frontend drips when you lift the blade than if your bottoming out. Sometimes you just need to lift the blade a bit just watch your temp. gauge, you don't want to block the radiator with the plow. Angle the plow to the right too, that allows more air flow.

I cranked mine on my old 88 when I added my Fisher plow.

Posted Image

#3 kdog55

kdog55

    Enthusiast

  • Member
  • 138 posts

Posted 31 December 2008 - 04:58 PM

I have the Western Ultramount on my '05 E/C also. My torsion is turned up quite a bit because I am running 285 tires and I still bottom out often because of how low these mounts are on the GM's. Even with the 285's those plow receivers only sit about a foot off the ground. I never leave the receivers installed when I am not plowing because of this. It's only 2 pins and I leave them sitting with the plow until needed.
For those unfamiliar with the Western Ultramount set-up, they actually sit BELOW the front airdam on my GMC and then hang down about 8 inches, plus stick out the front about 8 inches.

Edited by kdog55, 31 December 2008 - 05:00 PM.

Posted Image
2005 2500 HD/ 6.0 L/ BACKBEAR TUNED/ 285'S ON HELO 17X9 RIMS

#4 hd01chevy

hd01chevy

    Enthusiast

  • Member
  • 218 posts
  • Location:Celina,Ohio
  • Gender:Male

Posted 31 December 2008 - 05:40 PM

i installed a 8' boss on a 02 cc lb D-max and the torsion bars were cranked a lil allready but i also installed a timbren kit up front. Timbren is the company, and what they are is a hard rubber bout 3"tall that replaces the factory foam bumpstops. raised the front bout an inch over all. and only cost bout $200

#5 sheveman

sheveman

    Enthusiast

  • Member
  • 59 posts
  • Location:Erie, Pennsylvania
  • Gender:Male

Posted 31 December 2008 - 09:28 PM

I cranked the torsion bars on my 01 to level the stance of my truck, and it did help out with the bottoming out of the plow. i raised mine about 2 inches.. but remember to have the alignment checked afterwards because I didn't and it chewed up the front tires pretty quickly

Posted Image
2001 Silverado 2500HD 4X4, 8.1Vortec/Allison, extended cab, long bed

Posted Image

#6 Failanater

Failanater

    Hiding from the Clown! AAARRGGHH!

  • Banned
  • 8,207 posts
  • Location:Willow Sping, NC
  • Gender:Male

Posted 01 January 2009 - 12:18 AM

Happy New Year! :lol:
Posted Image

You dont have a gf do you??? :lol:

may be on to something. :lol:


#7 Riggs

Riggs

    Senior Enthusiast

  • Member
  • 1,939 posts
  • Location:Green Bay, WI
  • Gender:Male

Posted 01 January 2009 - 02:24 AM

Sometimes you have to turn up the torsion bars.. the plow mount is supposed to be a minimum of 15" off the ground on the GMT-900's for "The Boss" plows..

and when you put the mount on and even if you jam it all the way up as far as it will go its still an inch too low..
Posted Image
2006 GMC Sierra Ext. Cab 5'8" Box Z71 5.3 Vortec

My CarDomain

Old Truck's Car Domain

#8 coloradoSkiCountry

coloradoSkiCountry

    Senior Enthusiast

  • Banned
  • 2,138 posts
  • Location:Denver, Colorado
  • Gender:Male

Posted 01 January 2009 - 03:38 AM

"when you put the mount on and even if you jam it all the way up as far as it will go its still an inch too low."

That's what she said last night :thumbs: :crazy: :D
Posted Image

GM- Simply the best, and saying "To Hell with the rest!"

#9 bersh

bersh

    Enthusiast

  • Member
  • 133 posts
  • Location:Chassell, MI
  • Gender:Male

Posted 01 January 2009 - 12:35 PM

I have a 2003 2500HD, just had plow put on,7-1/2 pro plow ultramount, should i have the torsion bars turned up to help out seems to bottem pretty easy, going up driveway, is this commen??? and how do i go about adjusting if i do? how much do i go


I've got an 04 with an 8' Fisher HD plow, and I turned my bars about 1.5 turns. Just jack up the truck to take pressure off the torsions, I like to spray the bolts down good with a lubricant and let it soak for a couple minutes, then just take your time and crank them. Just keep track of how much you turn each one, and you may have to turn one bar more or less than the other to make sure the truck is level when you're done. Once you crank them and let the truck down, bounce on the front end or go for a drive, then take a measurement of each side to make sure they are the same. If not, adjust as needed. If you keep it under two turns, you shouldn't have to worry about the alignment. Come spring, you'll want to get the alignment checked anyway as having 700+ lbs. hanging on the front of the truck can affect it. On my old truck, a 94 1500, it really threw the alignment off every year. On the HD, it doesn't seem to affect it as much.

On my 04, I bought a set of timbrens, but never installed them as the truck handles the plow so well without them I didn't see the need. I got them for a screaming deal on ebay, so I sold them and made a few bucks on the deal. In retrospect, I should have just installed them as they do make a huge difference on how the truck handles the plow and they don't really affect the ride much at all. I had to install a set of timbrens on the 94, and it was a night and day difference. The install on the newer HD trucks is pretty easy, should only take maybe 15 minutes/side, and you might be able to do it without removing the wheels.

#10 sonjaab

sonjaab

    Member

  • Member
  • 2,158 posts
  • Location:syracuse ny
  • Gender:Male

Posted 02 January 2009 - 01:15 PM

Mark the T-bar bolt head and crossmember and turn each bolt a equal
amount of turns. In the summer turn them back down.
Those guys are correct about jacking up the front of the truck before
you turn the bolts as it makes them easier to turn...................

Remember turn clockwise to raise/counterclockwise to lower

So true these GMT-800 and 900s are lo-riders with the new plows and
will bottom out on anything!

For real help on anything snowplow check out: http://www.letstalksnow.com/forums
Avoid the clueless and children on plowsite!

Edited by sonjaab, 02 January 2009 - 01:16 PM.

Posted Image
Alexandria Bay NY & Syracuse NY
Daytona Beach FL
