LED Light Bar Installation Options

pcontant
 Share

Recommended Posts

pcontant Enthusiast

pcontant

Posted
Posted (edited)

Just got 2019 Sierra Elevation. Looking at options to install a 20 or 22” LED light bar. Had one in my bumper opening on my 2012 2500 HD and found it indispensable for night time driving in the backwoods.  Has anyone installed one yet?  Share your pictures of your setup if you have.



Thanks!

Edited by pcontant
Link to comment
Share on other sites
  • 5 months later...
pcontant Enthusiast

pcontant

Posted
  • Author
Posted

After months of waiting for a company to make brackets or someone to share ideas on a led bar install, I finally installed one today.  (Auxbeam 22” Curved) I cut a hole in the lower bumper plastic, made simple brackets, wired a relay (with freewheeling diode) off the high beams and voilà!!! The Sierra lights are very poor, especially in high beam - the lights create a blacked out horizontal band that drives me crazy.  Not anymore.



  • Like 2
Link to comment
Share on other sites
jordanl010 Enthusiast

jordanl010

Posted
Posted (edited)
18 hours ago, pcontant said:

After months of waiting for a company to make brackets or someone to share ideas on a led bar install, I finally installed one today.  (Auxbeam 22” Curved) I cut a hole in the lower bumper plastic, made simple brackets, wired a relay (with freewheeling diode) off the high beams and voilà!!! The Sierra lights are very poor, especially in high beam - the lights create a blacked out horizontal band that drives me crazy.  Not anymore.





Where did you wire your switch for this light bar? Or is it ran off your high beams?

Edited by jordanl010
Link to comment
Share on other sites
PabloK Enthusiast

PabloK

Posted
Posted

I'm going with a Rigid Industries SAE compliant 20 or 30 inch.



1.15 inches tall.  higher end setup...



https://www.rigidindustries.com/sr-series-20-dual-function-sae-auxilary-high-beam-driving-lights-920413.html





otherwise.... i would wait and let the market mature and catch up....  still lots of manufactures designing 2019 specific systems...



here's one for chevy that's very clean...



https://www.roughcountry.com/chevy-led-grille-kit-70817c.html?gclid=CjwKCAjwtuLrBRAlEiwAPVcZBilzSWGsteTAICdb4PmgnQ7U1L2hXBulORJ01Zqml9CgUXUfN0cfJhoCLLgQAvD_BwE&find=2019-gmc-sierra-1500-4wd-381260&sid=TfQY3m53yw



  • Like 1
Link to comment
Share on other sites
  • 2 weeks later...
  • 4 months later...
2k19Sierra Enthusiast

2k19Sierra

Posted
Posted
On 9/7/2019 at 10:04 PM, pcontant said:

After months of waiting for a company to make brackets or someone to share ideas on a led bar install, I finally installed one today.  (Auxbeam 22” Curved) I cut a hole in the lower bumper plastic, made simple brackets, wired a relay (with freewheeling diode) off the high beams and voilà!!! The Sierra lights are very poor, especially in high beam - the lights create a blacked out horizontal band that drives me crazy.  Not anymore.



Any chance you have some photos of the brackets you made and where you mounted them too?  This looks to me like the best place for a light bar on these trucks but nervous about cutting into the bumper...

Link to comment
Share on other sites
  • 5 months later...
  • 1 month later...
pcontant Enthusiast

pcontant

Posted
  • Author
Posted
On 7/26/2020 at 3:00 PM, Guyat4 said:

Did you have to remove the plastic piece that was cut out to mount the light? Or can I cut out with it on the truck. I have a 2020 GMC At4 and would like to mount the same light as you did.



Thanks!

I cut the opening without removing anything.  Worked out well!

Link to comment
Share on other sites
