  1. I have the same thing on my Onstar notification and I have LMZ Vleds installed on my truck. 2015 GMC Sierra SLT AT CC.
  2. Gloss blackTBSS replicas 20x9 +25 offset with 33x12.5r20 Toyo Open Country MT Sent from my iPhone using Tapatalk
  3. I was hoping the Bose amp had line level inputs from the radio. I really didn't want to use a line out converter for the system due to the chimes and Onstar coming through it as well. I was hoping to tie into the line level inputs(if it had them) and running my system. I'd keep the factory dash speakers hooked up to the Bose amp for chimes and Onstar and run my system off of my amp. But I'm guessing it's all run by a data signal and not actual line level inputs. I did notice on the far left black plug next to the brown plug there are six wires that are paired up. I was hoping that they might be inputs.
  4. I have a 2015 GMC SLT AT CC with Bose. I'm wanting to add a JL Audio 900/5 HD with a sub and components. My question is does the Bose amp use low voltage inputs or data signal for the audio in? From looking at all the wiring on the amp and the radio outputs I'm thinking it's using data for the inputs.
  5. You'll need to tap into the subwoofer output. You're tapped into the front outputs. The amp has already filtered them through the high pass crossover built in, so you're not getting any sub frequencies out of them. The sub outputs are as follows: Subwoofer (+) BLUE\GRAY PIN 1 Subwoofer (-) GRAY\BLACK PIN 5 Located in the black connector on the far right of the amp in your picture.
  6. I got it to work on mine. I have '15 Sierra SLT AT. I can receive text notifications only. I can't send any texts via MyLink or IntelliLink because iPhones don't support it. Thanks Apple. You're are correct about not receiving any other notifications though.
  7. I found this video on YouTube on accident. Now you can receive text notifications.
  8. I have a 2015 Sierra SLT All Terrain crew cab with Bose system. I'm wanting to replace the speakers with my Hertz 6.5 components, install a sub and run them with a JL 900/5 HD. Could I use an Audiocontrol DQ-61 off of the Bose amp inputs or outputs to run my JL 900/5? Or will the door chimes be too outrageous?
