28. Eight 0W20 Oils Tested and Compared
The following oils were tested in Spring 2016 for their Wear Protection Capability at the normal test temperature of 230*F, which is representative of normal operating conditions. They were also tested for their onset of Thermal Breakdown points, rounded to the nearest 5* increment. They are ranked here just among themselves, based on their film strength/load carrying capability/shear resistance psi values.
The Wear Protection reference categories are:
.
• Over 105,000 psi = INCREDIBLE wear protection
.
• 90,000 to 105,000 psi = OUTSTANDING wear protection
.
• 75,000 to 90,000 psi = GOOD wear protection
.
• 60,000 to 75,000 psi = MODEST wear protection
.
• Below 60,000 psi = UNDESIRABLE wear protection
.
The HIGHER the psi value, the BETTER the Wear Protection.
1. 0W20 Quaker State Ultimate Durability, API SN, synthetic (gold bottle) = 124,393 psi
Its onset of Thermal Breakdown = 270*F
.
.
2. 0W20 Toyota Motor Oil, API SN, synthetic = 101,460 psi
Its onset of Thermal Breakdown = 255*F
.
.
3. 0W20 Mobil 1 Extended Performance, API SN, dexos 1 approved, synthetic = 100,229 psi
Its onset of Thermal Breakdown = 265*F
.
.
4. 0W20 Pennzoil Platinum, Pure Plus Technology, made from Natural Gas, API SN, synthetic
(silver bottle with blue vertical stripe on the label) = 92,504 psi
It’s onset of Thermal Breakdown = 275*F
.
.
5. 0W20 Castrol Edge, Fluid Titanium Technology, API SN, dexos 1 approved, synthetic
(black bottle) = 90,745 psi
It’s onset of Thermal Breakdown = 270*F
.
.
6. 0W20 Valvoline SynPower, API SN, synthetic = 89,556 psi
It’s onset of Thermal Breakdown = 270*F
.
.
7. 0W20 Mobil 1 Advance Fuel Economy, API SN, dexos 1 approved, synthetic = 79,612 psi
It’s onset of Thermal Breakdown = 270*F
.
.
8. 0W20 Kendall GT-1, with liquid Titanium, API SN, synthetic = 71,385 psi
It’s onset of Thermal Breakdown = 260*F
.
.
As you can see, the wear protection capability of these oils varies widely. In fact, the number 1 ranked oil in this group, the 0W20 Quaker State Ultimate Durability, which is in the INCREDIBLE wear protection category, provides a WHOPPING 74% MORE wear protection than the last place 0W20 Kendall GT-1, which is only in the MODEST wear protection category.
Yet, if you look at the bottles, every single one of them boasts about the excellent wear protection they provide, to try and convince you to buy that product. But, obviously some of those claims do NOT stand up when put to the test.
So, if you did not have my test data as proof of their actual capability, and simply looked at the claims on the bottles instead, you would think all of them provide comparable wear protection. But, that is simply NOT the case. Motor Oil Companies are among the worst, for what some would call, blatant false advertising.
Unfortunately, since there is often no truth in advertising, it is in your best interest to never believe anything you read related to motor oil advertising. And that is why I started motor oil testing in the first place. To find out the truth about how various motor oils actually perform. Without my Wear Protection Ranking List, selecting the best oil for your engine, is only a guessing game.
