Yes, two ridges. One on each side. I didn’t remove the tailgate either. I opened the tailgate and removed the right side. I rested the open tailgate on a couple of plastic totes and swung it out to provide room to install. For spacers I used plastic chopsticks since I couldn’t find anything else laying around that was 1/4” Don’t laugh, it worked.
CWRKR changed their profile photo
I have a sunroof in my 2020 SLT. I love it even though I don’t use it as much as I should. I have had sunroofs in most of my vehicles and this is the only one not to make buffeting sounds when driving. I can actually drive on the highway with it open. It all depends what you end up paying for it. The only truck the dealer had with the color I wanted had the sunroof. At first I refused to pay it but ended up paying $300. I was told it adds $800 to the value at trade in.
I just installed mine today. I only removed the right side of the tail gate. Remove the cables Securing the tail gate and raise up the tail gate until the flats on the right hinge aligns with the cutouts on mount. Lift up at about 45 degree angle and remove tailgate from the bracket. I left the left side attached. There is enough play in the wiring to allow the tailgate to be pulled away from the bed enough to give room to work. I laid the tail gate on a couple totes to hold it flat without hanging down. Look at the instructions and ensure that the two outside light bar clips are installed 1/4”- 5/16” above the raised lip on the back of the bed at each end. If you don’t the lights will not be visible. I then used a string tied to the outside clips to align the heights of the two center clips. Then clipped in the light bar. Make sure you have enough tie wraps to secure the wiring underneath. Sorry I don’t have any picture currently. If you really need them I can take some. I apologize if my instructions are not understandable as I am multi-tasking.
