Finally getting around to Audio in this thing. I'm not going anywhere near as crazy as I did in my Silverado
I installed a Double Din Alpine W650 today, because I wanted Android Auto. I find it so convenient in my Silverado so I'll probably be installing it in all of my vehicles at some point. I also added a set of Alpine Type-S 6.5 components in the front. I never use rear speakers, so there's nothing hooked up back there.
Anyways, since my '99 Blazer came with a 1.5 din radio, I needed a couple of parts to convert to double din. A double din radio bezel out of a '03+ S10 or Blazer, or Olds Bravada. and a radio bracket adapter out of the Olds Bravada. I got lucky and found a Bravada at my local junk yard with everything I needed for $30.
Here's the bracket you need installed in my truck:
and here's the radio in the bracket, it lines it up perfectly.
you need to do a little trimming to the dash support to get it to fit, i took a picture of the Bravada with the bracket removed for reference.
and everything installed with the new double din bezel. I couldn't find one in light gray, but charcoal doesn't look bad with my interior either.
And I swapped the Infinity basslink out of my old Blazer. I got this thing for free years back, and it actually sounds decent.
