Anyone done an escalade interior swap?

[DaddyBlue]



[Savvy_Fox42]

22 minutes ago, DaddyBlue said:

Todd, is your 3500 4x4?  Did you have to add any transfer case wiring?  Did you leave the Escalade Electronic BrakesLarge plug unhooked?  I am currently working on a Escalade Platinum interior swap into my 2500HD Duramax 4x4.  I am looking for pointers.  Thanks Trevor



Two big things with the swap, the LBZ uses a high speed can line for the engine to trans to glow plug module connection that also goes to the obd2 port. I ran those into the escalade dash harness. Mine was not 4wd, but AFAIK you should just overlay the wires for the 4x4 switch setup and be fine. Second, I had to de pin a few of the wires from the large escalade brake / chassis control connector for the rear lights and abs stuff. The escalade i got my interior from was a 6.0 AWD model so the connectors might be different. PM me if you need more wiring help.

[lbz4me]

On 3/5/2023 at 6:32 PM, Savvy_Fox42 said:



Two big things with the swap, the LBZ uses a high speed can line for the engine to trans to glow plug module connection that also goes to the obd2 port. I ran those into the escalade dash harness. Mine was not 4wd, but AFAIK you should just overlay the wires for the 4x4 switch setup and be fine. Second, I had to de pin a few of the wires from the large escalade brake / chassis control connector for the rear lights and abs stuff. The escalade i got my interior from was a 6.0 AWD model so the connectors might be different. PM me if you need more wiring help.



On 3/5/2023 at 6:32 PM, Savvy_Fox42 said:



Two big things with the swap, the LBZ uses a high speed can line for the engine to trans to glow plug module connection that also goes to the obd2 port. I ran those into the escalade dash harness. Mine was not 4wd, but AFAIK you should just overlay the wires for the 4x4 switch setup and be fine. Second, I had to de pin a few of the wires from the large escalade brake / chassis control connector for the rear lights and abs stuff. The escalade i got my interior from was a 6.0 AWD model so the connectors might be different. PM me if you need more wiring help.

Exactly what wires did you have to remove from the Silverado? Harness, and add to the escalade harness. Can you be specific
