Help Identifying OBD and DLC Connectors.

[R34P3R]

So... either i'm stupid... or the internet is lying to me. What is the difference between the OBD and DLC connectors and where are the located?

2007 Classic Silverado 4.3L.



This site calls them OBDs

http://www.obd-2.de/carcode/tech_dlc-gmp.html



but this image says different

[kstruckcountry]

OBD plug is right next to the emergency brake release.

[R34P3R]

Ok that answers that... but what about the DLC? Where is that located?

[MikeNH]

Same port, multiple names. To further confuse you I know some old timers who still call it an ALDL- assembly line diagnostic link.

[R34P3R]



Humans.....



thanks for the info guys.

[citydriver]

Same port, multiple names. To further confuse you I know some old timers who still call it an ALDL- assembly line diagnostic link.



HEY, who are you calling an Old Timer? LOL jk
