Dave sagert

How to get thru firewall in front of driver

Recommended Posts

Need to put a wire thru the firewall. I only see one grommet and it looks like it goes to washer motor

Share this post


Link to post
Share on other sites

What size wire? There is a small nipple on the main grommet on driver's side.

Sent from my SM-N960U using Tapatalk

  • Like 1

Share this post


Link to post
Share on other sites

I'm with 1slow, there is a main harness down further from where the washer hose is. It's like 2 inches maybe or larger. There is a tiny nipple on the top of the grommet. I used a old metal coat hanger to feed in 3 12gauge wires for my remote start when I hooked up an aftermarket one. I plan to shove a single run of 0 gauge in there too next year for my system and if I can't I will make a hole just next to it and have it's own grommet for it.

Share this post


Link to post
Share on other sites

If you lift up the driver door sill trim and look under the carpet there is a rubber grommet.  This is where the company that installed my topper ran wires for power.  I used the same access to run wires from my left-side fuse panel to a camera on my front bumper.  All wires are protected. out of sight and no drilling or coat hangers required!

Share this post


Link to post
Share on other sites

This thread has a pic of the grommet



Here is another option if that doesn’t work out for you





Share this post


Link to post
Share on other sites
