Existing engine battery 2015 Silverado 1500

Dickiedodo

By Dickiedodo
in Modifications & Accessories

Recommended Posts

Dickiedodo Enthusiast

Dickiedodo

Posted
Posted

I just picked up new Silverado and want to install a second battery.

I know about the isolator and required wiring of which is no problem to me.



My concern is wiring into the existing battery on the positive terminal. It appears there is no place to tap my new wiring.



The cover on the battery with the usable links is there a spare? I hav not removed the snap cover for the fuses.

Any advice or if any one has taped into the existing battery would be helpful

Thank you

Dick

chuckl1218 Senior Enthusiast

chuckl1218

Posted
Posted

Is there a spare post under the cover?

Thank you

Dick

There should be. I know there is on the 2014's.
DanY Enthusiast

DanY

Posted
Posted

Spare post but no nut on it. Not knowing the thread size, I just doubled up on one of the populated posts.

07Softail Senior Enthusiast

07Softail

Posted
Posted

just wondering do you live in the artic to need a second battery, these trucks are pretty good starters even in Canada where apparently it gets cold lol

LMAO!!!!



RT

Dickiedodo Enthusiast

Dickiedodo

Posted
  • Author
Posted

No I don't live in the Artic. I plan to run an 110 volt inverter off the second battery. I will use a Cole hersee battery isolator between the two batteries.



Dick

Dickiedodo Enthusiast

Dickiedodo

Posted
  • Author
Posted

I plan to use a 750-1000 watt may be a big. But will not use device that draw that much, being on the higher capacity than going to small is better. I realize that the one battery will not give me much time if using a high wattage device.

That is ok as I will not need long running time on a device

I have a motorhome and and use two large inverters but have six batteries. I am familiar with these devices and the correct wiring.

The Silverado has a small inverter and has a 110 out let in the cab but is not sufficient for my application.

I am a photographer and also shoot Astro at night. Many times I am out all night.



Dick

morrislee Enthusiast

morrislee

Posted
Posted

For your information, I have mine setup in parallel with no isolator for months. No issues so far.



I even made my own positive terminal cover and it is spotless when I opened it couple of days ago.

Dickiedodo Enthusiast

Dickiedodo

Posted
  • Author
Posted

In the answer to the photo question. If your interested the sky and milkyway use a wide angle lens with the widest aperature. I use a 24 mm 1.8 for sky and milkyway.



Next

What did you make the positive terminal cover out of? Can you supply an image of it both on and off the battery?

The reason I will use an isolator because of using the inverter and I can run the battery quite low with out compromising the start battery



Thank you



Dick

morrislee Enthusiast

morrislee

Posted
Posted

In the answer to the photo question. If your interested the sky and milkyway use a wide angle lens with the widest aperature. I use a 24 mm 1.8 for sky and milkyway.



Next

What did you make the positive terminal cover out of? Can you supply an image of it both on and off the battery?

The reason I will use an isolator because of using the inverter and I can run the battery quite low with out compromising the start battery



Thank you



Dick



You can find the pictures below. I have a plastic soft cup below the clamp connection and the top black cover is made from flange shipping cover, I have added some JB weld to all the seams to make it stronger.



http://www.gm-trucks.com/forums/topic/157013-what-have-you-done-to-your-k2-today/page-242?do=findComment&comment=1628264
