Nickel Plated Slip Yoke

Gryphon

Recommended Posts

Gryphon Enthusiast

Gryphon

Posted
Posted

I am SICK of greasing that damn thing every few weeks and I want a permanent solution, but I'm not foolish enough to pay the local dealer some $500 for one. Could someone please provide the GM part number for the nickel plated slip yoke so I can order it online? Thanks.

gnon18s New Member

gnon18s

Posted
Posted
I am SICK of greasing that damn thing every few weeks and I want a permanent solution, but I'm not foolish enough to pay the local dealer some $500 for one. Could someone please provide the GM part number for the nickel plated slip yoke so I can order it online? Thanks.





+1 Looking for the same thing.. They should be handing them out for free. Not charging $500 for there screw up!!

jrrod2004 Senior Enthusiast

jrrod2004

Posted
Posted

Clunk, Bump or Squawk when Vehicle Comes to Complete Stop or Accelerating from Complete Stop or Accelerating from Complete Stop (Replace Rear Drive Shaft Nickel-Plated Slip Yoke) #01-04-17-004B - (Jan 5, 2005)Clunk, Bump or Squawk when Vehicle Comes to Complete Stop or Accelerating from Complete Stop (Replace Rear Drive Shaft Nickel-Plated Slip Yoke)

1999-2000 Cadillac Escalade (Old Style)



2002-2004 Cadillac Escalade, Escalade EXT



2003-2004 Cadillac Escalade ESV



1996-1999 Chevrolet 1500 Series Extended Cab Short Box Pickup (Old Style)



1996-1999 Chevrolet 1500 Series Regular Cab Pickup and Utility Models (Old Style)



1999-2002 Chevrolet Silverado Extended Cab Short Box (New Style)



1999-2004 Chevrolet Silverado 1500 Series Regular Cab (New Style)



2000-2004 Chevrolet 1500 Series Avalanche, Suburban and Tahoe



2001-2004 Chevrolet Silverado 2500/3500 Series Regular Cab with Long Bed or Extended Cab (New Style)



2001-2004 Chevrolet Silverado 2500 Series Crew Cab, Short Box (New Style)



1996-1999 GMC 1500 Series Extended Cab Short Box Pickup (Old Style)



1996-1999 GMC 1500 Series Regular Cab Pickup and Utility Models (Old Style)



1999-2002 GMC Sierra Extended Cab Short Box (New Style)



1999-2004 GMC Sierra 1500 Series Regular Cab (New Style)



2000-2004 GMC 1500 Series Yukon, Yukon XL



2001-2004 GMC Sierra 2500/3500 Series Regular Cab with Long Bed or Extended Cab (New Style)



2001-2004 GMC Sierra 2500 Series Crew Cab, Short Box (New Style)



2003-2005 HUMMER H2



with Four Wheel Drive (4WD) or All Wheel Drive (AWD) and One-Piece Propeller Shaft ONLY



This bulletin is being revised to add Cadillac Escalade (Old Style) and HUMMER H2 to the Models section. Please discard Corporate Bulletin Number 01-04-17-004A (Section 04 -- Driveline/Axle).



Condition

Some customers may comment on a clunk, bump or squawk noise when the vehicle comes to a stop or when accelerating from a complete stop.



Cause

A slip/stick condition between the transfer case output shaft and the driveshaft slip yoke may cause this condition.





Part Number

Description

Usage



12477702

Yoke Asm., Prop Shf Slip (with u-joint) , Nickel Plated

4WD/AWD 1500 Series Ext Cab Short Box Pickups (New Style and Old Style)



12477704

Yoke Asm., Prop Shf Slip (with u-joint) , Nickel Plated

4WD/AWD 2500 Series Ext Cab Short Box Pickups (New Style)



12479383

Yoke Asm., Prop Shf Slip (without u-joint) , Nickel Plated



Must Be Ordered With U-Joint Kit P/N 12479126

4WD/AWD 1500 Series Silverado, Sierra Regular Cab Pickups (New Style)



4WD/AWD 1500 Series Suburban, Avalanche, Yukon XL, Escalade EXT, Escalade ESV with AWD (New Style)



K1500 Series Regular Cab Pickup, Tahoe, Suburban, Escalade (Old Style)



12479384

Yoke Asm., Prop Shf Slip, (without u-joint) , Nickel Plated



Must Be Ordered With U-Joint Kit P/N 12479126

4WD/AWD 1500 Series Tahoe, Yukon, Escalade w/ 4WD or AWD (New Style)



12479385

Yoke Asm., Prop Shf Slip (without u-joint) , Nickel Plated



Must Be Ordered With U-Joint Kit P/N 12471510

4WD/AWD 2500HD/3500 Series Silverado and Sierra Regular Cab, Long Bed Pickups with 6.0L (RPO LQ4) Engine (New Style)



89058876

Yoke Asm., Prop Shf Slip (with u-joint) , Nickel Plated

4WD/AWD 2500HD Series Silverado and Sierra Crew Cab, Short Bed Pickups with 5-Speed Allison Transmission (RPO M74) (New Style)



4WD 2500HD/3500 Series Silverado and Sierra Extended Cab Long Bed Pickups with 5-Speed Allison Transmission (RPO M74) (New Style)



4WD 2500HD/3500 Series Silverado and Sierra Regular Cab, Long Bed Pickups with 5-Speed Allison Transmission (RPO M74 build date before 2/2004) (New Style)



4WD/AWD 2500HD Series Silverado and Sierra Extended Cab, Short Bed Pickups with 5-Speed Allison Transmission (RPO M74 build date before 2/2004) (New Style)



89058878

Yoke Asm., Prop Shf Slip (with u-joint) , Nickel Plated

4WD/AWD 2500HD/3500 Series Silverado and Sierra Extended Cab Pickups with 6.0L (RPO LQ4) Engine (New Style)



4WD 2500HD Series Silverado and Sierra Crew Cab, Short Bed Pickups with 6.0L (RPO LQ4) Engine (New Style)



89058880

Yoke Asm., Prop Shf Slip (with u-joint) , Nickel Plated

4WD/AWD 2500HD/3500 Series Silverado and Sierra Regular Cab, Long Bed Pickups with 5-Speed Allison Transmission (RPO M74 build date after 2/2004) or 6-Speed Manual Transmission (RPO ML6) (New Style)



4WD 2500HD Series Silverado and Sierra Extended Cab, Short Bed Pickups with 5-Speed Allison Transmission (RPO M74 build date after 2/2004) or 6-Speed Manual Transmission (RPO ML6) (New Style)



12479126

U Joint Kit

4WD/AWD 1500 Series Silverado, Sierra Regular Cab Pickups (New Style)



4WD 1500 Series Suburban, Avalanche, Yukon XL) (Escalade EXT, Escalade ESV with AWD (New Style)



4WD 1500 Regular Cab Pickup, Tahoe, Suburban, Escalade (Old Style)



Tahoe, Yukon, Escalade w/ 4WD or AWD (New Style)



12471510

U Joint Kit

4WD/AWD 2500HD/3500 Series Silverado and Sierra Regular Cab, Long Bed Pickups with 6.0L (RPO LQ4) Engine (New Style)



88964470

Yoke Asm., Prop Sft Slip (without U joint) Nickel Plated



Must be ordered with U joint kit P/N 88964507

HUMMER H2



88964507

U-Joint

HUMMER H2







that is all I could find....

Ape0r Enthusiast

Ape0r

Posted
Posted

Greasing the piss out of mine with a heavy marine grade grease I found at Autozone has kept it quiet for almost three years now...

jrrod2004 Senior Enthusiast

jrrod2004

Posted
Posted
Jesus. Which one of those would be for an '05 Sierra ECSB Z71 4x4?? The first one, 12477702?





I'd assume so...

pm26 Senior Enthusiast

pm26

Posted
Posted
Greasing the piss out of mine with a heavy marine grade grease I found at Autozone has kept it quiet for almost three years now...



When time comes to grease mine I will use Triple Guard Grease which is really thick and sticky waterproof marine grease which is used on propeller shafts in sea water.

pm26 Senior Enthusiast

pm26

Posted
Posted

Is it true that the nickel plated slip yoke has been replaced with a gold plated yoke to justify the $ 500 price tag? :)

Gryphon Enthusiast

Gryphon

Posted
  • Author
Posted

I tried marine grease, no dice. I just had the intermediate shaft relubed for clunking, and now I'm getting a tapping noise coming from behind the dash. I'm getting pretty pissed! Nothing I can't stand more than rattling-type noises on my vehicle. I got so pissed at that dash rattle the other day I pulled over on the highway and ripped the frigging thing apart looking for it. Still avoiding me. :(



EDIT: Define "greasing the piss out of". All I've been doing is coating the splines with a good layer but nothing TOO crazy. Am I supposed to dump the entire 8 oz tube into there or what? I'm about at that point.

bossier62guy Senior Enthusiast

bossier62guy

Posted
Posted
I tried marine grease, no dice. I just had the intermediate shaft relubed for clunking, and now I'm getting a tapping noise coming from behind the dash. I'm getting pretty pissed! Nothing I can't stand more than rattling-type noises on my vehicle. I got so pissed at that dash rattle the other day I pulled over on the highway and ripped the frigging thing apart looking for it. Still avoiding me. :(



EDIT: Define "greasing the piss out of". All I've been doing is coating the splines with a good layer but nothing TOO crazy. Am I supposed to dump the entire 8 oz tube into there or what? I'm about at that point.



That "tapping" noise you are referring to might be the lower steering column bearing. I know ever since I got rid of the intermediate steering shaft noises I can definitely hear that lower bearing when driving over rough surfaces. There is a "fix" using a hose clamp located somewhere on this site. I have yet to try it on my truck but I think I'm just going to replace the bearing itself.

  • 5 years later...
eoyrs76 New Member

eoyrs76

Posted
Posted

I've go an 04 Silverado. I have a new slip yoke part #88963576, but is it nickel plated? I can't tell.

ram1067 Enthusiast

ram1067

Posted
Posted

I can live with this....what really pisses me off is the constant "Groan like a dying goose" when turn at low speeds! :banghead:

This has been a problem for many years! I still have not found a definite fix. thanks GM :idiot:

Archived

This topic is now archived and is closed to further replies.
