Factory Wheel specs

Mass2500HD

By Mass2500HD
in Modifications & Accessories

 Share

Recommended Posts

Mass2500HD Enthusiast

Mass2500HD

Posted
Posted (edited)

Does anyone know the offset for the 20" 10 spoke aluminum wheels? I believe they are either a 20x9" or a 20x8.5". Can anyone validate? Anyone know the offset? On chevy's build side and accessory side of the web, they just state 20"




Edited by Mass2500HD
Jettech1 Senior Enthusiast

Jettech1

Posted
Posted (edited)

That's a good question.  Here's what I found on google... I hope this helps.  This actually educated me too because I thought it was 20x9.  I was wrong.  It's 20x8





This Factory OEM CHEVROLET rim comes equipped on a 2020 - 2022 CHEVROLET SILVERADO 2500 . This is a ALLOY wheel with a diameter of 20" width of 8 ". This CHEVROLET SILVERADO 2500 wheel has 8 lug holes and a bolt pattern of 8-180. The offset of this CHEVROLET SILVERADO 2500 rim is 47mm.

Edited by Jettech1
Sonders Enthusiast

Sonders

Posted
Posted

I liked those wheels when I first got my truck; thought they were different.  Now that I've had the truck for a year I'm already growing tired of them and want something that actually has a little bit of lip.  Going to stick it out until it's time to replace tires.

Jettech1 Senior Enthusiast

Jettech1

Posted
Posted
6 hours ago, Sonders said:

I liked those wheels when I first got my truck; thought they were different.  Now that I've had the truck for a year I'm already growing tired of them and want something that actually has a little bit of lip.  Going to stick it out until it's time to replace tires.

I actually love those wheels.  In all my years of owning vehicles, I've only had one that I put different wheels on and that was my beloved 71 Chevy Biscayne that I bought back in 1982.  The poor mans Impala back then lol...I put on some Cragar mags on a 4 door Chevy Biscayne.  But it looked great!!  No really it did...lol....

Jettech1 Senior Enthusiast

Jettech1

Posted
Posted
6 hours ago, Another JR said:




No, I do not like those wheels.

In 2020 the center portion of the wheel was black.  I didn't like that.  It was too contrasting with the aluminum in my opinion.  They went to gray either in 21 or 22.  Now I like them, actually love them.

Buckwild27 Enthusiast

Buckwild27

Posted
Posted

Factory 17x7.5 Wheel Offset = +44 mm - Back Space = 5.98" Inches

Factory 18x8.0 Wheel Offset = +44 mm - Back Space = 6.20" Inches

Factory 20x8.5 Wheel Offset = +47 mm - Back Space = 6.60" Inches

Lug Pattern= 8 x 180 - Single Rear Wheel Trucks Only

  • Like 1
Sonders Enthusiast

Sonders

Posted
Posted
15 hours ago, Jettech1 said:

I actually love those wheels.  In all my years of owning vehicles, I've only had one that I put different wheels on and that was my beloved 71 Chevy Biscayne that I bought back in 1982.  The poor mans Impala back then lol...I put on some Cragar mags on a 4 door Chevy Biscayne.  But it looked great!!  No really it did...lol....

I just wish they weren't so narrow.  If they were an inch or two wider and maybe had a lip on them, they'd be much better.  But as they are, they remind me of pizza cutters.  I'll probably keep them as I don't feel like messing with aftermarket wheels though.



Homewrecker, thanks for providing the specs that OP asked for.  Sorry I distracted from the original post.

  • Like 1
  • 2 weeks later...
newdude Senior Enthusiast

newdude

Posted
Posted
4 minutes ago, Maninthesea said:

Wait.  There is a 17” option?   I thought 18’s were min. To fit over brakes.





17" is standard on 2500hd for two trims.  Steel on WT, aluminum on LT.



All 1 ton minimum is 18" because of the higher load rated tires to go with the higher GVWRs.
