gunner25 Enthusiast

gunner25

Posted
Posted
On 10/24/2020 at 1:09 PM, swaptrex14 said:

Got the fender molding painted and frosted fender lights






On 10/24/2020 at 1:09 PM, swaptrex14 said:

Got the fender molding painted and frosted fender lights




That looks awesome! What size tires/wheel/level?

  • Replies 578
  • Created
  • Last Reply

Top Posters In This Topic

Popular Days

Top Posters In This Topic

Popular Days

Popular Posts

joelabq
joelabq

Yessir!! I'm loving the new front end look! Sent from my LG-H932 using Tapatalk

gSwift
gSwift

I think it's WAAAAY too much white, but to each their own.

Thebelow25
Thebelow25

20x10 fuel sledge wheels. Toyo m/t tires

Posted Images

swaptrex14 Enthusiast

swaptrex14

Posted
Posted
17 minutes ago, gunner25 said:



That looks awesome! What size tires/wheel/level?

Thanks



20” Fuel Rebels (Anthracite) wrapped in Terra Grappler G2 35’s


ProComp 2.5 level

kylant Enthusiast

kylant

Posted
Posted
17 hours ago, gSwift said:

So here is the finished product and here are the parts i used



Cognito 3" Premier leveling kit with external reservoir Fox shocks.

Cognito "PISK"

SuspensionMAXX 1.5" rear block

SuspensionMAXX Diff drop

Venum 1" wheel spacers/adaptors

37x12.50 Nitto Ridge Grapplers on OEM AT4 wheels



I don't remember the exact factory height before the lift, but i'm pretty sure it had 1.75" of rake. I wanted to keep some rake so I added a 1.5" rear block.

New measurements are

LF 38.5       RF 38.5

LR 38.75    RR 39.5



I'll probably attempt to dial that in a little a see if I can get the numbers a little closer.



Angles are good and the ride is amazing with the external resi shocks. Had to do some trimming on the liners and the mud flaps, but it all turned out pretty clean and I'm super happy with it. As @kylant mentioned to me, the 37's rubbed on the Cognito control arms, so I added a hubcentric 1" spacer and then took it to Firestone for a lifetime alignment and now everything is perfect.


looks great!

where are you taking your measurements from? ground to bottom of fenders?

gSwift Enthusiast

gSwift

Posted
Posted
3 hours ago, kylant said:

looks great!

where are you taking your measurements from? ground to bottom of fenders?

Sorry, I actually meant to list that.  I measured from the bottom of my 20" wheel to the groove cut into the GMC fender flares. It just seemed like a cleaner line to measure from but I may go back and re-measure

gSwift Enthusiast

gSwift

Posted
Posted
4 hours ago, kylant said:

looks great!

where are you taking your measurements from? ground to bottom of fenders?

I updated my original post to reflect the measurements from the ground to the bottom of the fender.

MNDakota Enthusiast

MNDakota

Posted
Posted

Swapped out the halogen headlight/housings for LEDs I bought wrecked off eBay. JB welded the housings back together, polished the scratches out of the lenses and now, from the outside, they look like new. I also used the Gen5DIY harness to make it simple.






  • Like 1
swaptrex14 Enthusiast

swaptrex14

Posted
Posted
3 minutes ago, doozer78 said:

Looks good!

Sent from my SM-A705U using Tapatalk


Thanks, turned out great.  I mixed white and clear for the lenses and covered with a few coats of frosted clear.

JB23 Enthusiast

JB23

Posted
Posted
6 hours ago, swaptrex14 said:


Looks great man! Your rig is lookin sharp!

  • Thanks 1
Stand By Enthusiast

Stand By

Posted
Posted
On 11/3/2020 at 7:12 AM, MNDakota said:

Swapped out the halogen headlight/housings for LEDs I bought wrecked off eBay. JB welded the housings back together, polished the scratches out of the lenses and now, from the outside, they look like new. I also used the Gen5DIY harness to make it simple.






By chance have you looked or done any comparison of the halogen housings against the led, for possibly swapping the internals from one to the other?

MNDakota Enthusiast

MNDakota

Posted
Posted
12 hours ago, Stand By said:

By chance have you looked or done any comparison of the halogen housings against the led, for possibly swapping the internals from one to the other?

From what I can tell, the housings and lenses are identical. Pretty sure the part numbers for the bare moldings we're the same. I'm keeping the old headlights for now in case the refurbished lenses fog up (although good halogen headlights are going for more than I paid for the LED's on eBay). If they do fog up, my plan is to swap the internals to the halogen housings. I just didn't want to mess with them too much yet.
