L83 Cam Swap

Evanski9

By Evanski9
in Engines & Drivetrain

Recommended Posts

  • Replies 96
  • Created
  • Last Reply
rjw Enthusiast

rjw

Posted
Posted

By the way, don't forget to do a C.A.S.E. learn with the PCM after doing a cam swap. It sync's up the camshaft timing to the cam sensor for more accurate spark and fuel injector firing. I did this with every cam swap I did in the 99-07 trucks. :)



I thought it was only when changing pcm's ?

hirdlej Enthusiast

hirdlej

Posted
Posted

Nope, a C.A.S.E. learn should be performed whenever changing anything related to valve timing. Chain, sprockets, camshaft.







I thought it was only when changing pcm's ?



rjw Enthusiast

rjw

Posted
Posted

Nope, a C.A.S.E. learn should be performed whenever changing anything related to valve timing. Chain, sprockets, camshaft.









all I have is crankshaft learn. when I click on it I get a message to slowly accelerate to fuel cutoff. I click on OK and do so...should I get a message that it was succesful? Also, is fuel cutoff 4k while in case learn??



thx

hirdlej Enthusiast

hirdlej

Posted
Posted

I'm not sure if the same parameters need to be met on the new trucks, but on the 99-07's the procedure was to get engine up to temp, apply both e-brake, regular foot brake and have truck in park. In HP Tuners I clicked on the learn button and then pushed through the throttle until the fuel cutoff around 4-5k rpm. I did it so fast that I never even looked at the tach. I think it is 4k RPM though if my memory serves me correct. It's simply and only takes a few seconds.

rjw Enthusiast

rjw

Posted
Posted

I'm not sure if the same parameters need to be met on the new trucks, but on the 99-07's the procedure was to get engine up to temp, apply both e-brake, regular foot brake and have truck in park. In HP Tuners I clicked on the learn button and then pushed through the throttle until the fuel cutoff around 4-5k rpm. I did it so fast that I never even looked at the tach. I think it is 4k RPM though if my memory serves me correct. It's simply and only takes a few seconds.



I think that things are different on the 2105 with E92 ecm.... thanks

truckguy82 Senior Enthusiast

truckguy82

Posted
Posted

You guys are crazy for wanting to install an lt1 cam. The 6.2's only make 65 more hp than the 5.3. I don't think the cam is a big part of the equation.



For a part in which the install labor is the primary expense, I'd probably go with a better cam.

rjw Enthusiast

rjw

Posted
Posted

You guys are crazy for wanting to install an lt1 cam. The 6.2's only make 65 more hp than the 5.3. I don't think the cam is a big part of the equation.



For a part in which the install labor is the primary expense, I'd probably go with a better cam.



LT4 cam...$140 delivered, ....better fuel lobe, and is a blower cam......not looking for 700 hp on a daily driver



If I had to do the cam again, labor would be cut in 1/4.....

07Softail Senior Enthusiast

07Softail

Posted
Posted

Sure it's capable of 600+ but doesn't mean you have to reach for max effort. It would work well at 550+ easy while retaining it's timing features and again it's cheap!



RT

  • 1 month later...
Lupe Figueroa New Member

Lupe Figueroa

Posted
Posted

I have a 2016 5.3 silverado, I installed the cam that comes factory on the 2016 z06 corvette, I'm installing a turbo and this cam produces more fuel at the mechanical fuel pump that comes on the l83 motor, this is a big job since you are supposed to remove the heads but I work at Chevy and we did it without having to, a lot easier, the computer adjusted itself and the truck ran like if no changes had been made, I decided to tune it before installing the turbo with the new cam and it went from 10.02 to 9.6 in the 1/8 mile my truck is a short bed single cab with factory 3.42 gears with posi traction, next time I'll try it with e85 fuel before I install my t88 precision turbo which should give me around 650 hp to the wheels without having to reinforce the bottom end or replacing any other parts.

Meethead Enthusiast

Meethead

Posted
Posted

Has Anyone completed a cam swap on the Ecotec3 l83 motor yet? I would love to swap for a nice cam on my 2016.



Which cam did you go with?

Which Pushrods?

Which springs?



Any video of the idle and performance?

Meethead Enthusiast

Meethead

Posted
Posted

Did some searching around on the net this morning. I cam upon this site with a couple selections. Curious if anyone has seen these.



http://www.briantooleyracing.com/gen-v-vvt-non-afm-223-228-604-604-114-6.html (Seems like this does not requires anything else other than AFM disable.)



Also not sure about this either.

"A torque converter change may be needed in some L83 applications. "



They also have a kit with CAM, PR and Spring with retainers

http://www.briantooleyracing.com/btr-gen-v-lt1-l83-l86-cam-kit.html
