Another oil thread

[customboss]

On 12/10/2023 at 6:22 PM, Grumpy Bear said:

@Customboss, have you run an unused oil sample on this product?

Yes

[Grumpy Bear]

Zinc Matters



Lake Speed Jr. But SwRI running the test. Lake consults with Total Seal.





[Grumpy Bear]

Break in Matters



Note wear metals are normalized to 1,000 miles.





[Grumpy Bear]

Watch this video front to back. What do you think the disconnect is between the condition of the majority of the motor and the state the pistons and rings are in.





[MaverickZ71]

On 2/11/2024 at 3:16 PM, Grumpy Bear said:

Zinc Matters



Lake Speed Jr. But SwRI running the test. Lake consults with Total Seal.







Zinc does matter.  Especially on classic car engines with flat-tappet cams (no roller lifters).  You can buy a bottle of ZDDP additive, but the manufacturers all say IT WILL KILL YOUR CATALYTIC CONVERTER.  I call BS on that. The first cats were the restrictive pellet type, and the zinc content in motor oil was 50% higher back then, and everybody's cats weren't plugging up!

Edited March 2, 2024 by MaverickZ71

[Grumpy Bear]

4 hours ago, MaverickZ71 said:



Zinc does matter.  Especially on classic car engines with flat-tappet cams (no roller lifters).  You can buy a bottle of ZDDP additive, but the manufacturers all say IT WILL KILL YOUR CATALYTIC CONVERTOR.  I call BS on that. The first cats were the restrictive pellet type, and the zinc content in motor oil was 50% higher back then, and everybody's cats weren't plugging up!



I've been pumping oil through Dizzy for 157,500 miles. Haven't killed he cats yet. Or the O2's.

[MaverickZ71]

1 hour ago, Grumpy Bear said:



I've been pumping oil through Dizzy for 157,500 miles. Haven't killed he cats yet. Or the O2's.



We've poured enough oil into the 09 Silverado that we should've had stock in Shell Oil.

[OnTheReel]

The OEMs have to warranty the cats longer than the engine so it’s no surprise they cut back the ZDDP.

[customboss]

Fuel dilution of engine oil will cause higher levels of ZDDP/ZDTP to cause severe wear. Soot from GDI and even diesel DI becomes a third party abrasive mechanically.  When we EGR our blow-by that is literally liquid fuel phase and non polar post EGR soot from fuel the ZDDP is gonna wear your engine.



Why I am testing a 0 ZDDP engine oil in the L3B 2.7L so I don't end up like Grumpy's Terrain.



https://link.springer.com/article/10.1007/s11249-018-1115-x



Abstract :



Diesel engines and gasoline direct injection (GDI) engines both produce soot due to incomplete combustion of the fuel and some enters the lubricant where it accumulates between drain intervals, promoting wear of rubbing engine components. Currently the most favoured mechanism for this wear is that the anti-wear additives present in engine oils, primarily zinc dialkyldithiophosphates (ZDDPs), react very rapidly with rubbing surfaces to form relatively soft reaction products. These are easily abraded by soot, resulting in a corrosive-abrasive wear mechanism. This study has explored the impact of engine oil dispersant additives on this type of wear using combinations of dispersant, ZDDP and carbon black, a soot surrogate. It has been found that both the concentration and type of dispersant are critical in influencing wear. With most dispersants studied, wear becomes very high over an intermediate dispersant concentration range of ca 0.1–0.4 wt% N, with both lower and higher dispersant levels showing much less wear. However a few dispersants appear able to suppress high wear by ZDDP and carbon black over the whole concentration range. A series of experiments have been carried out to determine the origin of this behaviour and it is believed that high levels of dispersant, and, for a few dispersants, all concentration levels, protect the iron sulphide tribofilm initially formed by ZDDP from abrasion by carbon black.

[customboss]

Gosh, no commentary?  Hmmm

[Grumpy Bear]

On 3/2/2024 at 2:37 PM, OnTheReel said:

The OEMs have to warranty the cats longer than the engine so it’s no surprise they cut back the ZDDP.



There is a study that suggest wear in a GDI motor is the result of ZDDP. It its abstract it makes several MISLEADING STATEMENTS that create the illusion of a problem where none exist except in the cases of extreme neglect. Soot is produced in EVERY motor, not just GDI and yes that includes E-85 and E-100 motors. IF that didn't make your mind go directly to 'level of soot concentration' then you are asleep at the wheel. ZDDP level isn't a problem in ANY SAE oil classification used in a healthy motor with a reasonable OCI.



Consider. Million-mile Diesel engines have always been direct injection. Since their invention in the 1800's. Who used more ZDDP and DISPERSANT than the Commercial Diesel platform.



What has changed? AFTERTREATMENT. and RECOMMENDED OCI LENGTH. This has NOTHING to do with wear and everything to do with those changes. EPA and C.A.F.E.



In a gas motor, you ever have a UOA return anything but a ZERO for soot in a healthy motor with a reasonable OCI.



Why a dispersant? To isolate soot and prevent amalgamation to a size that causes a 'three body wear" issue. Use your noggin. What has to happen for soot to cause soft deposits in the ZDDP layer?  DISPERSANT DEPLEATION. When does that happen? When the concentration of soot DEPLETES the dispersant level. When does that happen? When you don't change your oil often enough.



Change Your Oil

























Edited April 9, 2024 by Grumpy Bear

[diyer2]

Change your oil, what a concept. My standard for years.

[Grumpy Bear]

On 4/9/2024 at 9:15 AM, diyer2 said:

Change your oil, what a concept. My standard for years.



Changing Oil? Has it EVER been a question?



Aristotle didn't invent logic any more than Newton invented gravity. Does someone think objects fell upward before that day? All these guys did was explain what was already true in a way the rest of us could understand. It is the point after all. To elevate, not suppress. To make useful, not waste. And the know the difference.



Did ZDDP all the sudden be come DESTRCUTIVE? LOGIC TEST. Did all the major blenders just turn into idiots? LOGIC TEST. One fella wants us all to think so.....



Oh, it's coming (zero ZDDP) and we can't stop it and new chemistries will need to be and in fact are being developed. BUT this doesn't cancel what has always been true nor ZDDP's effectiveness for as long as we have access to it.  Put up laughy emojis till the cows come home. I ain't buying it. The shy didn't fall.



ZDDP: When, Where, What, Why, How? - Engine Builder Magazine



Government regulations and demands for lower emissions levels become more important than power and performance. Proven components are no longer acceptable and the inevitable changes occur – not always for the best.



Things seemed to be much simpler in the 1930s. Engine bearings were made from a soft tin/copper/antimony alloy, commonly referred to as babbit. This alloy is relatively inert chemically and has the ability to absorb small amounts of foreign particular material. But, as engine horsepower increased, babbit alloy surfaces proved to be inadequate to bear the increased loading on these surfaces.



Harder bearings of cadmium/silver, cadmium/nickel, and copper/lead construction were developed. These bearings were much stronger, but were not as chemically inert as babbit and could be attacked by the acids generated from oil oxidation. They were also unable to absorb foreign material such as grit and wear debris into the bearing material and improvements in oil filtration were developed.



Bearing corrosion inhibitors, anti-wear agents and acid inhibitor compounds were developed to protect these new bearings. Protection for bearings against both corrosive and mechanical wear was needed and many of these compounds served both functions. These compounds included sulfurized sperm oil, organic phosphates, dithiocarbonates and dithiophosphates. In 1941, the oil and gasoline additive company Lubrizol developed Zinc Dialkyl Dithio Phosphates, or ZDDP.



Commonly referred to simply as “Zinc” in today’s vernacular. ZDDP was first used in low concentrations (less than .3%) as a bearing passivator (meaning “to treat or coat a metal in order to reduce the chemical reactivity of its surface”). It also acts as an oil anti-oxidant. In addition, it was found to be a remarkably effective anti-wear agent, a true extreme pressure or EP additive for heavily loaded steel-on-steel sliding mechanisms such as camshafts and valve lifters or tappets.



For years, these additives provided sufficient anti-wear service in the early days of gasoline non-detergent motor oils. Diesel engines of the time, which generally operated at lower speeds and were more massively built, did not exhibit the same wear problems. But in a gasoline engine, the valve train is more heavily stressed due to the higher engine speeds.



This produces high sliding speed and friction between camshaft and lifters, which tend to be poorly lubricated since they are dependent on oil splash for lubrication. High impact loads also resulted from the reaction between cam lifter, pushrod, and the rocker.



Impacts in this system start at the camshaft and ending at the valve stem were increased in severity as valve spring pressures and thus loading increased. These loads cause scuffing from metal-to-metal contact. Small additions of additives such as ZDDP were sufficient to provide anti-wear protection for these mechanical parts.



Diesel engine oils contained detergent additives to combat the pollutants caused by diesel fuels and their combustion. There were many failures with heavy wear resulting particularly in the cam and tappets when attempts were first made to use diesel oils containing detergents or to introduce detergent additives into the oils of gasoline engines.



Theories abounded. It was erroneously thought that these detergents were either chemically attacking the metal or that these metallic compounds were actually abrading the metal surfaces. The problem is simply real estate – there is only so much metal surfaces for the boundary layer and anti-wear additives in the oil to attach.



And because most detergents do not have significant anti-wear capability, the surfaces become unprotected, and wear takes place where loads are the heaviest. To overcome this, a concentration of anti-wear additive, such as ZDDP, must be increased substantially to compete successfully with the detergent and get some measure of protection to these metal surfaces.



The American Petroleum Institute (API) standards for auto and diesel oils are represented by the alphabetical codes we see on the containers. The “S” is the automotive designation and this stands for “Service.” Heavy-duty diesel oils carry a “C” designation, which stands for “Commercial.”



Some are simply no longer useful: SA contains no additives and was designed for engines built before 1930; SB was for engines previous to 1951; SC for engines previous to 1967 and so on up to SH, now obsolete, which was for engines built in 1996 or older.



Today we can still find SJ-for 2001 and older automotive engines, SL-for 2004 and older automotive engines and the most current SM. The API service category for SM oil reads as follows:



“For all automotive engines currently in use. Introduced in 2004, SM oils are designed to provide improved oxidation resistance, improved deposit protection, better wear protection, and better low-temperature performance over the life of the oil. Some SM oils may also meet the latest ILSAC specification and/or qualify as Energy Conserving.”



In 1992, an API-rated SH oil contained 1,200 parts per million (ppm) of phosphorus; in 1996 SJ contained 1,000 ppm. It was not until 2001, when the rating went to SL, that we all started to see camshaft problems appear.



In 2001, SL-rated oil still contained 1,000 ppm of phosphorous, and it is the phosphorous that limits are set on. But this limits the amount of ZDDP an oil manufacturer can use. The rating was changed due to demands for increased engine cleanliness standards.



Higher levels of detergents were introduced to meet these standards and camshaft problems began. It was not until 2004, when SM rated oils, with their limited 800 ppm phosphorus were introduced, that cam failures greatly increased.



Why then, you ask, have API standards pushed for higher detergent levels and lower levels of ZDDP? ZDDP attacks or “poisons” catalytic converters. The same attraction properties that allow it to adhere to or “plate” cams and lifters also happens to the catalyst in converters, thus rendering them ineffective.



Conversely, detergents have the same “cleaning effect” on the catalyst as they do on metal surfaces inside the engine.  I must point out that these phosphorus level mandates are on SAE 10W-30 and lower viscosity grades only.



Most higher viscosity grades have adopted lower phosphorus content levels, but it was not mandated. They still must meet the higher detergent and dispersant levels to meet the API cleanliness requirements of an SM rating.



The then-current CJ-4 rated diesel oil had a phosphorus limit of 1,200 ppm. There were no previous limits to the amount of phosphorus or sulfur in “C” rated oils. But the high level of detergents and dispersants in diesel oil still compete with the ZDDP for metal surface areas.



ZDDP is a “class” of additives today, not just one particular chemical. These additives are the predominant anti-wear agents. Because diesel engines tend to run considerably hotter around the piston rings, ZDDP tends to decompose and produces a lacquer on cylinder walls. But, because of their heavy duty design and superior metallurgy, they have fewer wear problems than their gasoline counterparts.



For simpler diesel oil, a more stable, less potent form of ZDDP can be used. When developing multipurpose motor oils, for gasoline engines and high-speed passenger car diesel engines, careful decisions must be made in selecting the form of ZDDP, or a balanced mixture of 2 or more types may be used.



This is also true when comparing break-in oil, API rated motor oils for street use and true racing oils. A different type or types are used to control the rate of time the additives work to “plate” and “maintain” their protective barrier shield.



Concerns for the poisoning effect caused by ZDDP to catalytic converters have caused restrictions for its use in some countries. Japan has maintained a maximum limit on phosphorus of 0.05% for many years, while most countries have a limit set at 0.1%. In October of 2010, API SN/ILSAC GF-5 oils hit the shelves.



The requirements for an SN rating are the same 800 ppm maximum of phosphorus, but a new test has been added. A phosphorus retention test that may require the use of different or alternative ZDDP compounds.



The effects of these alternate additives on older flat tappet camshafts and valve train are just beginning to be seen, but can include roller camshaft wear!  More changes are slated to come. California is even debating legislation that would require the complete removal of some additives, including ZDDP.



Some of today’s motor oils can have strong negative effects on older, non-roller lifter design engines as we all have found. It becomes more important as valve train loads increase to use oils that are designed specifically for flat tappet camshafts, as in the use of high performance camshafts and high-pressure valve springs.



Dave Sutton’s sources for this column include Lake Speed, Jr – Certified Lubrication Specialist & Member of the Society of Tribologists and Lubrication Engineers;  The American Petroleum Institute web-site; www.gf-5.com website; and the “SAE Automotive Lubricants Reference Book.” You can reach Dave at [email protected].









[customboss]

On 4/9/2024 at 7:47 AM, Grumpy Bear said:



There is a study that suggest wear in a GDI motor is the result of ZDDP. It its abstract it makes several MISLEADING STATEMENTS that create the illusion of a problem where none exist except in the cases of extreme neglect. Soot is produced in EVERY motor, not just GDI and yes that includes E-85 and E-100 motors. IF that didn't make your mind go directly to 'level of soot concentration' then you are asleep at the wheel. ZDDP level isn't a problem in ANY SAE oil classification used in a healthy motor with a reasonable OCI.



Consider. Million-mile Diesel engines have always been direct injection. Since their invention in the 1800's. Who used more ZDDP and DISPERSANT than the Commercial Diesel platform.



What has changed? AFTERTREATMENT. and RECOMMENDED OCI LENGTH. This has NOTHING to do with wear and everything to do with those changes. EPA and C.A.F.E.



In a gas motor, you ever have a UOA return anything but a ZERO for soot in a healthy motor with a reasonable OCI.



Why a dispersant? To isolate soot and prevent amalgamation to a size that causes a 'three body wear" issue. Use your noggin. What has to happen for soot to cause soft deposits in the ZDDP layer?  DISPERSANT DEPLEATION. When does that happen? When the concentration of soot DEPLETES the dispersant level. When does that happen? When you don't change your oil often enough.



Change Your Oil

























The GDI or DDI soot construct and post EGR re-construct reacts abnormally with ZDTP and ZDDP.



Ignore it at your own engines risk.



Why the fuel we use is the most critical factor NOT THE ENGINE OIL.   Why the AIR FILTER is more critical for our DI engines making fine soots than the oil filter because the engine will R-E-T-A-R-D  timing ,change VVT cam phasing, fueling for even  a slightly restricted air filter ( especially for turbo engines).  Changing your oil more often is too late to correct for these things.  I'll repeat that again below because many here thick about this subject.



Since most of us run the current E10 gasolines or  (E0 gasolines with higher levels of octane boosters that MAKE EVEN more of the soot )........ that is about to be mandated to be filtered out the tail pipe since its so small and easily absorbed into humans lungs.  Gas Particulate Filters are a thing coming.  GPF



Wake up Grumpy ( and other uniformed followers)  you are a on the cheap  "hand waver" of epic proportions here on GM-Trucks.  Stop overtly dismissing anything you can't grasp like many here.





Changing your oil more often doesn't stop the production in our engines of DI induced problems.



Worked on a 95,000 mile 2014 Terrain 3.6L V6 last weekend because the owner believed all the things you promote here and he changed the oil at less than 3000 miles with mobil 1.  His deposits are everywhere the oil can't correct.  The area below the compression ring is clean. He has switched to E15 and after 3 cleanings of valve train area its running better finally.  No wonder the  GM 3.6 V6 is shot at 125,000 if it works that long.



That clear enough Grumps?





Edited April 10, 2024 by customboss

[customboss]

On 11/14/2023 at 10:44 PM, Grumpy Bear said:

One of the things Blackstone got right was a large library of engine types and factory tune levels base on drain intervals. The service may be McDonalds, but the library is Porterhouse

There is no measure of TUNE levels since they have never done FTIR, GC, or KF and have no data to correlate to their part of the story.  The library is lacking so your idea of a porterhouse in science is in fact a chicken tender.
