So the 2020 HD models standard bed is now longer ?

f8l vnm

Recommended Posts

f8l vnm Senior Enthusiast

f8l vnm

Posted
Posted

Can someone confirm this ?  I think they went from 6/6 inches to 6/9 inches .. Like Ford and their SD line



Thanks k

newdude Senior Enthusiast

newdude

Posted
Posted

Its in the press release:  https://media.chevrolet.com/media/us/en/chevrolet/vehicles/silveradohd/2020.html



Quote



DuraBed: The segment’s most functional HD cargo box
The 2020 Silverado HD’s DuraBed builds on the breakthrough cargo box technologies and features introduced on the redesigned 2019 Silverado 1500 to offer the segment’s most functional HD bed.

For the first time on Silverado, the HD cargo boxes are not shared with the light-duty models. They are designed specifically for the HD with unique dimensions, but still incorporate the multi-piece inner panels (previously a single panel) design and strong, rolled-steel box construction featured on the Silverado 1500.

The multi-piece inner panels allow them to be pushed closer to box’s outer panels in certain areas, expanding the usable width by 6.7 inches on the standard box, compared to the current model. The box length is also about 3 inches longer on the standard box, extending length, adding volume and extra clearance for longer items. The long box length remains 8 feet long. With the extra width enabled by the multi-piece inner panel construction, the total cargo box volume expands 14 percent and about 9.5 percent, respectively, on the standard and long boxes. The larger volume for the long box — 83.5 cubic feet — is class-leading.

Standard Box (6’ 9”)



2020 Silverado HD

2019 Silverado HD

Dimension Change

Box Length at Floor:

82.2 in. (2089 mm)

78.8 in. (2003 mm)

+3.4 in. (86 mm)

Box Height:

21 in. (533 mm)

21.1 in. (536 mm)

-0.1 in (2.5 mm)

Box Width between Wheelhousings:

51.9 in. (1317 mm)

51 in. (1296 mm)

+0.9 in. (21 mm)

Max Box Volume:

69.6 cu. ft. (1970 L)

61 cu. ft. (1728 L)

+8.6 cu. ft. (242 L)

Box Lift-In Height:

38.9 in. (988 mm)

39.8 in. (1010 mm)

-0.9 in. (21 mm)


Long Box (8’)



2020 Silverado HD

2019 Silverado HD

Dimension Change

Box Length at Floor:

98.3 in. (2496 mm)

97.8 in. (2483 mm)

+0.5 in. (13 mm)

Box Height:

21 in. (533 mm)

21.2 in. (536 mm)

-0.2 in (3 mm)

Box Width between Wheelhousings:

50.6 in. (1284 mm)

51 in. (1296 mm)

-0.4 in. (12 mm)

Max Box Volume:

83.5 cu. ft. (2364 L)

76.4 cu. ft. (2162 L)

+7.1 cu. ft. (202 L)

Box Lift-In Height:

38.8 in. (986 mm)

39.6 in. (1005 mm)

-0.8 in. (19 mm)



I'd call it confirmed.

CRApex Enthusiast

CRApex

Posted
Posted

What is the overall length on the Crew with standard bed?  I have a feeling it won't fit in my garage.

ApertureX Enthusiast

ApertureX

Posted
Posted
3 hours ago, CRApex said:

What is the overall length on the Crew with standard bed?  I have a feeling it won't fit in my garage.

Same media website linked above. There is A LOT of information there:

EXTERIOR DIMENSIONS



Regular Cab

Double Cab

Crew Cab

Wheelbase
(in. / mm):

141.5 / 3595 (long box)

149.4 / 3795 (std. box)
162.4 / 4127 (long box)

158.9 / 4037 (std. box)
172 / 4369 (long box)

Overall Length
(in. / mm):

235.5 / 5982 (long box)

240.4 / 6107 (std. box)
256.4 / 6514 (long box)

250 / 6349 (std. box)
266 / 6756 (long box)

Overall Width (in. / mm):

81.9 / 2079 (SRW)
96.7 / 2457 (DRW)

81.9 / 2079 (SRW)
96.7 / 2457 (DRW)

81.9 / 2079 (SRW)
96.7 / 2457 (DRW)

Overall Height
(in. / mm):

79.8 / 2027

79.8 / 2027

79.8 / 2027

Front Track
(in. / mm):

68.1 / 1731

68.1 / 1731

68.1 / 1731

Rear Track
(in. / mm):

68.3 / 1736 (SRW)
75 / 1905 (DRW)

68.3 / 1736 (SRW)
75 / 1905 (DRW)

68.3 / 1736 (SRW)
75 / 1905 (DRW)

m5guy Enthusiast

m5guy

Posted
Posted

Yep - Standard box, crew cab overall length now 10.5 inches longer.  I have 14 inches of clearance in my garage with my current '17 Denali.  Not parking outside (I'm too high maintenance for that).  Might be a deal breaker for me. :(

ApertureX Enthusiast

ApertureX

Posted
Posted
9 minutes ago, m5guy said:

Yep - Standard box, crew cab overall length now 10.5 inches longer.  I have 14 inches of clearance in my garage with my current '17 Denali.  Not parking outside (I'm too high maintenance for that).  Might be a deal breaker for me. :(

You'll still have 4" left. just put 2" in the front and 2" in the back using the new cameras. :D







P.S. Trying really hard not to post the all "inches" comments I have in my head right now.:angel:

m5guy Enthusiast

m5guy

Posted
Posted
1 minute ago, ApertureX said:

You'll still have 4" left. just put 2" in the front and 2" in the back using the new cameras. :D

Sounds easy!  Not to get specific, but 3.5 inches - have to put inch and three-quarters on each end.  I've measured - very precisely.

ApertureX Enthusiast

ApertureX

Posted
Posted
5 minutes ago, m5guy said:

Sounds easy!  Not to get specific, but 3.5 inches - have to put inch and three-quarters on each end.  I've measured - very precisely.

Time for a remodel...


CRApex Enthusiast

CRApex

Posted
Posted

It would fit in mine with roughly 1.5” on either side.  Chevrolet should have called me to find out my garage size before they designed the new trucks.

m5guy Enthusiast

m5guy

Posted
Posted
19 hours ago, ApertureX said:

Time for a remodel...


You, my friend, have your priorities right!

  • 2 weeks later...
2018GMC Senior Enthusiast

2018GMC

Posted
Posted

The T1XX HD is larger in every aspect compared to K2xx HD.



Yes, interior space improved but the truck is now taller, longer and wider.



I wonder if fuel economy will be less than K2xx, like how people reporting in the half ton T1xx are getting less mpg than their K2xx.



Glad GM didn’t downsize the fuel tank in the HD like they did in the LD.
