Thought I'd post a review of the newly installed suspension and wheel set up on my 2016 GMC Sierra Denali 1500. Previous set up was stock MagneRide suspension with ride height sensors and 22" stock wheels with Nitto Terra Grappler G2's size 285/45r22. I'm at 70k miles and the ride was steadily getting worse (too stiff), so I researched for a while and ended up installing the following:
HaloLifts Boss Ultimate Kit (adjustable coilovers for 1" to 3" of lift in front, and 1" of lift in the rear) - http://www.halolifts.com/HaloLifts-Boss-Ultimate-Kit-fits-your-2007-UP-GM-SilveradoSierra-1500_p_220.html Stock GMC Sierra 18" rims (powder coated black) with Falken Wildpeak AT3W's size 275/70r18 Bypass sensor kit for all 4 MagneRide shock sensors and all 4 ride height sensors (I removed all ride height sensors that are mounted to the frame) - http://www.xineering.com/shocksims.html
Up first, the HaloLifts Boss Ultimate Kit
At $1299, this is a more expensive kit vs the Fox, Bilstein, or Rancho equivalant. What swayed me to this kit was that I was not looking for a crazy lift and I wanted something that was plug and play should I go a different route once these start to fail (like all shocks eventually do). Additionally, I found multiple reviews on this forum and other brand forums where people said they had installed Fox, Bilstein, and/or other brands and this was the best riding kit and worth the extra cash. You'll find a rep from the company, Alex, who's posted in this forum, as well as others, and he says call him with any questions. I did, and he answered every time and would not let me go until I had EVERY question answered. The customer service is outstanding with this place. I ended up going with the coilovers set at 1.5" of lift and I put .5" spacers beneath it to get 2" of total lift and the softest ride possible. Each kit is made custom to what you want, so that's how it arrived for me. You can have the coilovers set at 2" if you want, then add 1" of spacers underneath. Since I am only doing 2" of lift, I did not purchase new UCA's. Below are pics of me opening the packages. Again, thoroughly impressed with how sealed everything was with plenty of foam and cardboard to protect everything. Install was a breeze, thanks to instructions that were included and my convo with him over the phone. One last thing, the "do the rear shock boots go down or up?" debate has been settled. According to HaloLifts they go down :-)
Next, the new wheel/tire set up
I downsized from a 22" set up to an 18" set up so I could get more sidewall and a softer ride. While I like the look of a larger rim, it was so easy to get scratches on the 22" rims since they are so close to the ground and there's not enough sidewall on the tire to bulge out a little bit to help protect the rims. So, new set up gets me a softer ride and better rim protection. I went with a stock rim and had it powder coated black because I've had mixed experience with aftermarket rims (good and bad). As far as the tire choice, Falken Wildpeaks kept coming up as best all around value for it's performance. I've had KO2's in the past, as well as other AT tires but I wasn't blown away by their performance for how much you spend on them. Falken's were cheaper, but hold up well in rain, snow, and mud. Plus they have an aggressive look, that's a nice bonus. Below are pics of the truck with the new wheel and suspension set up. I'll follow that up with the obligatory, "pardon the dirty truck, haven't had time to wash it".
Last, the MagneRide bypass kit
This only applies to those who have the MagneRide suspension and ride height sensors (certain trims like Denali). If you do have it, you'll need to bypass the sensors or you'll forever be dismissing a message that says "service suspension system". If you can live with that, then ignore all of this. If it'll drive you nuts, you have 2 options - one cheap, but could lead to other issues and the other is not so cheap, but will not have issues. There are 8 sensors total, 4 shock sensors and 4 ride height sensors. The first option is to go cheap and buy 8 resistors (3 ohm, 25 watts). You then splice them in at every sensor. The risk here is corrosion, if you don't seal the splices properly this leads to the wire harnesses going bad and having to purchase all new harnesses and resistors to do all of the work again (and now you've spent more money on the harnesses). In all, this could run you about $50 for resistors, heat shrink, and a heat gun. The second option is to do what I did and buy the professional bypass kit from x-ineering. It's $425, but they'll give you a $75 discount if you post about your install on social media. I went this route because they clip in and seal the wiring, just like the stock sensors. No risk of corrosion and everything they make is backed by warranty.
Overall, I'm super happy and love the ride. Only a couple hundred miles on it so far, I'll report back after all my Thanksgiving travel coming up (1500+ miles). Let me know if there are any questions!
Ordering new tires this week... my 275/60R20 BFG''s are near the end and wont make it through winter. I've been reading for hours and have narrowed down to TerrainContact AT or BFG KO2 again. Also debating stock 55's versus 60's. Any advice and pictures would be helpful...
New to this forum. I'm leasing a White 2017 GMC Sierra SLE that, based on the price and looks (not a fan of the new wheel well shape) of new trucks I may just buy out in a few months. If I keep it, I would like to look at doing a few things to it. Like I said, I don't off road or hunt or haul a lot of stuff. I like it because there is room in the cab, it's great in the winter, I can haul stuff if I need to, but basically its just a big car for me. I have steps and a roll up box cover.
I like my truck a lot just as it is. I have the 5.3 V8. It's enough for my needs. I don't really need a lot of after market performance. I'd like to make it as comfortable as possible and to look good but not over the top. I'd like it to be not quite stock but not a show piece if that makes sense. Like you look at it and say I'm not sire why but like the look of that truck.
Leveling kit: Don't need a lift but would lie the front and back to match.
Wheels and tires: I'd probably stick to almost factory. I have stock 18x9 (P265/65/R18) rims and tires. I was thinking maybe 18x10 for just a little more width to fill up the wells a bit. Tire needs to be a good all season as I mostly drive on roads.
Debadging: I like the clean look.
Ambient lighting: I have an SLE so not much for options. I do have bed lighting which is nice. I like lights and think some subtle additions inside might be nice.
Those are my initial thoughts. What do you all suggest?
Yeah, I know. ANother tire thread. Ugh.
But before you shoot me, I've got a slightly different kinda tire issue...
Well, my Goodyear SRA's bit the dust, so after a bunch of research, I decided on a set of Falken Wildpeak A/T3W in 275/65R18. I have now been back to Discount Tire three times for a constant vibration problem that will just not go away. DT has been awesome, no issue with them. I really had high hopes for these tires (they are SOOO much better in the rain than the SRA's), but they're just not working for me. I'm thinking one of them is out of round, though a couple of them took (what I thought was) a lot of weight to balance out, over 6oz. This is my 2nd set of Falken tires (had them on a Focus a number of years ago), so I've lost confidence in them. Anyhow...
Discount Tire has offered to take them back and get me into another tire. I think I have narrowed it down to 2 different ones, trying to stay in my budget. I don't need a LT tire, to heavy for my needs. I think the choices that fit me the best are:
Cooper Discoverer AT3 Nitto Terra Grappler G2
I want an AT tire, but the BFG KO2's are out of my price range. I've ruled out a couple of others for one reason or another, so I'm leaning more towards the Nitto. Opinions? Thoughts?
By Hexa Fox
Hey guys just wanted to say that I really appreciate all the help from this community. I have recently made a couple posts and got a lot of great advice. I was deciding whether or not I should go through all the maintenance on my truck or trade it in, with the help of this community I have decided to keep the truck.
Anyway one of my biggest concerns is the ride quality of my truck. I recently went from the following tires (link) to a pair of Michelins that I am not even sure how to describe. I was talked into putting them on my truck at Costco. My truck has rode terrible ever since then, I am sort of avoiding driving it now and hate that.
I took it to a certified Goodyear dealer today and he said they were all terrain tires and designed for the road. You will be able to see this is true from the pictures that I am about to post. They look more like "highway" tires than the previous ones I had from the link provided. So my door recommends that I run 35 PSI in the tires and right now they have around 40 PSI if I am not mistaken. That might have a lot to do with it. However, my tire pressure sensors are already telling me to check them and believe that they are probably have at least 37 PSI in them. The following link I found will show you what they are.
So I know there is a way to program the location of the sensors, but can I program them for a different PSI reading?
Also what why would these top of the line tires be riding much rougher than the previous linked ones?
As always and advice is greatly appreciated gentleman!
