I recently installed the upgraded digital dash in our LTZ that did not have it thanks to White Automotive. The process turned out to be quite a bit more daunting than I had expected. I had found a few posts (here and another better start here) that talked about upgrading the gauge cluster, however I could not find any specific step by step instructions to gain access.
With plenty of reasons for everyone to access the radio, center console, and gauge cluster, I thought a step by step tutorial would make the project immensely easier for anyone willing to do it. And trust me, If I can do it, you can do it.
This "How To" is in first draft form. I just wanted to get it out there for anyone who wants to do this or has been struggling with how to get the specific trim pieces that are required off.
Photos will be added to this tutorial after Christmas
A Video will be added to this tutorial after New Years
7mm socket with 6 inch extension & ⅜ ratchet , plastic interior trim removal tools, T15 Torx bit
Plastic Interior Trim Removal Tools are absolutely necessary. Using metal tools or screw drivers will 100% damage your interior!
We used this kit from Amazon that costs around $16. <------ This is not a referral link. Just being helpful and showing as an example.
Prepare by cleaning out center console, cup holders, charging area, side console storage areas, and by moving the front driver/passenger seats backwards.
Using towels, create a soft area to store interior pieces during work
Pry infotainment decorative chrome/painted trim away, starting at the bottom around the HVAC vents on each side, then the top. Remove square access cover directly next to the accelerator pedal. Remove the 7mm screw under the decorative cover. Place fingers in drivers side footwell console storage area and use moderate force to pull the side of the center console away. You do not have the totally remove the panel. There are approximately 8 clips to pull loose towards the top and front of the panel. Do the same on the passenger side, however there is no screw to remove before the panel will snap out. There are approximately 8 clips to pull loose. You do not have to totally remove the panel. With the center console lid open, use a pry tool to pop the clips holding the top of the center console area to the center console assembly. Pull up and disconnect approximately 10 clips around the cup holders, charging pad and/or storage pad area and up to directly below the radio/climate controls. Do not yank the trim too far away, there are wires connected to the bottom of this trim piece. Gently position the tray as far rearward as possible without removing the wires, or gently remove the wire connectors and place the console on your soft area. Using a pry tool, remove the thin, curved piece of trim directly under the piano key switches. There are five clips to remove, each releasing directly towards the rear of the vehicle, parallel to the floor of the vehicle. Release two clips on each side then pull gently to remove the center clip. Position console tray (if still attached) to remove two T15 screws at bottom of infotainment/climate control unit. Unscrew top four T15 screws holding infotainment/climate control in place at top of unit. Using pry bar, pull infotainment unit away, releasing approximately 8 clips around the unit. Use caution, HVAC ducting will come out with the unit, so only pull directly out. Disconnect Unit or lean out to continue on for access to gauge cluster. Using a plastic pry tool, release the leather infotainment trim, but only along the side of the cluster. Using a plastic pry tool, remove the leather gauge cluster hood. The approximately 6 clips are released pulling straight up. Remove the fuse access panel on the driver’s side door opening. Using a T15 bit, remove the two screws holding the HVAC/switch unit in place. Using a pry tool, pull the HVAC/switch unit directly away from the dash. There are approximately 8 clips holding it in place. Unscrew three 7mm screws holding the front cluster trim piece in place. Using your hands, pry the cluster trim piece away from behind the steering wheel, including the trim piece on the top of the steering wheel column that is attached. Remove four 7mm screws holding gauge cluster in place. For 2019 trucks, slide red locking tab and lift cam lock to remove cluster harness. Reverse steps to reassemble.
Please comment with any suggestions, edits, or comments. I'd like this to be as helpful as possible.
By Tyler Sywykk
My issue is a little bit different however none the less an annoying one. So yesterday i bought some led bulbs off amazon to replace the dome lights in my truck, i got them opened them up all looks good and then go to put them in, and as i did they turned on not an issue however they where to small so i have to return them, i put the old one back in and not lights in the dash and dome lights are acting up. So it was the left front one i tried it in and took it back out no others. Now none of the lights turn on by the button inside the truck. (door lights and turning them on by the small switch which turns them all on works just fine. when the door is open i can now turn the light off by pressing the button. now those issues are a little less of a bother to me, however the radio (which still works perfect) now has no lights, same with the driver info center buttons 4wd actuator light and the lights on the steering wheel lights. All the buttons however still work perfect it is just the lights. Any help is much appreciated !
Truck is a 2008 GMC sierra 2500HD SLE Diesel crew cab long box
Currently have my 2020 Gmc sierra 1500 with a build date of 09/2019 at the dealer with 2kmiles on it. Battery was dead one morning. After jump starting had check engine light and brake antilock system issue sent to my email. Truck would not hold a charge after leaving it on for a good 30 min. Its been at the dealer for 3days now.
I just purchased a 2011 gmc 2500hd Denali with 157000 miles on it. When the rpms are just below 2000 the needle spikes to 2000 and drops back, as if surging. It downshifts fine. If you try to gradually accelerate at that point it shudders as if in to low a gear. I have not tried pulling anything with this truck yet, but wanted to get an idea whether or not I have a serious problem or not.
I took it it to a dealer to have a diagnostics ran on it and the tech couldn’t get power to the tester, so before I tackle that issue I wanted to see if I had a major issue. According to some of these forums this looks to be a issue on a lot of newer trucks.
any experience with this issue would help.
